Shop CENTURY

Pool Pump Motor, Permanent Split Capacitor, 19/50, 3 HP, 56Y Frame, 3,450/1,725 Nameplate RPM

  • Mfr # B2987

  • Zoro # G8651420

product price:  $802.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Dripproof
HP
19/50, 3
RPM Range
3,001-3,600
Motor Service Factor
1.15
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
B2987
Zoro #
G8651420
UPC #
-
Country of Origin
United States

Dimensions

Shaft Length
1 in
Shaft Dia.
5/8 in
Overall Length
14 3/8 in
Bolt Circle Dia.
7 3/16 in
Height
11 in
Length Less Shaft
13 3/4 in
Shaft Diameter
5/8 in
Frame Size
56Y
Body Diameter
6.5 in
Bolt Circle Diameter
7 3/16 in

Details

Item
Pool and Spa Pump Motor
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Dripproof
HP
19/50, 3
RPM Range
3,001-3,600
Motor Service Factor
1.15
Nameplate RPM
3,450/1,725
Frame
56Y
Motor Shaft Rotation
CCWSE
Phase
Single
Voltage
230V AC
Full Load Amps
15.0/2.6 A
Motor Mounting Type
Face
Ins. Class
F
Max. Ambient Temp.
50 Degrees C
Shaft Material
303 Stainless Steel
Motor Application
Pump
Shaft
Threaded
Motor Thermal Protection
Auto
Motor Sub Application
Pool and Spa Pump
Ambient Temperature
50 Degrees C
Motor Flange Material
Aluminum
Hz
60 Hz
Finish
Unfinished
Motor Bearings
Ball
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
Standards
CSA (LR4642), UL (E44549)
Weight
43 lb
Motor Frame Material
Steel
Usable @ 200V
Not Usable at 200V
Duty Cycle
Continuous
Usable @ 208V
Not Usable at 208V
Motor Shaft Design
Threaded
Motor Mounting Position
Horizontal
No. of Speeds
2
Conduit Box Position
F3
Efficiency Rating
Standard Efficiency (IE1)
Shaft Design
Threaded
Ambient Temperature - Maximum
50 Degrees C
Application
Pump
Number of Wires
18
Insulation Class
F
Motor Enclosure Type
Open Drip Proof
Full Load Current @ 60 Hz
15.0/2.6 A
Frame Finish
Unfinished
Product Type
Pump Motor
Frequency
60 Hz
Nameplate Service Factor @ 60 Hz
1.15
Frame Material
Steel
Bearing Type
Ball
Mounting Position
Horizontal
Number of Speeds
2
Sub Application
Pool and Spa Pump

Description

Pool and Spa Pump Motor, Bolt Circle Dia. 7 3/16 in, Conduit Box Position F3, Duty Cycle Continuous, Finish Unfinished, Frame 56Y, Hz 60 Hz, Full Load Amps 15.0/2.6, Height 11 in, HP 19/50, 3, Ins. Class F, Length Less Shaft 13 3/4 in, Max. Ambient Temp. 50 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Permanent Split Capacitor, Motor Efficiency Group Standard Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel

Restrictions

This item has been restricted from sale in the following states: CA, NY
