Shop CHICAGO PNEUMATIC

1/2" Pistol Grip Air Impact Wrench 220 ft.-lb.

  • Mfr # CP7737

  • Zoro # G3729595

product price:  $296.99
/ea
Free Shipping & Returns

Key Features

Square Drive Size
1/2"
Free Speed
9,000 RPM
Air Inlet
1/4 in NPT
Handle Type
Pistol-Grip
Max. Torque
220 ft.-lb.
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CP7737
Zoro #
G3729595
UPC #
015451761158
Country of Origin
Taiwan, Province of China

Dimensions

Square Drive Size
1/2"
Overall Length
9 3/8 in
Anvil Length - Air Impacts
0.750"
Air Inlet Size - Air Tools
1/4" NPT
Drive Size - Air Tools
1/2" Square
Min. Hose Size
3/8 in
Drive Size
1/2 in
Extended Anvil Length
2 in
Hose Size - Minimum
3/8 in
Air Inlet Connection Size
1/4 in

Details

Item
Air Impact Wrench
Free Speed
9,000 RPM
Air Inlet
1/4 in NPT
Handle Type
Pistol-Grip
Max. Torque
220 ft.-lb.
Features
Full Teasing Trigger, Single Handed Forward - Reverse Operation, Steel Motor
Retainer Type
Friction Ring
Tool Weight
2.5 lb
Handle Material
Composite
Blows per Minute
1600
Style
Pistol Grip
Retainer Type - Air Impacts
Ring
CFM @ Full Load
17.0
Housing Material
Aluminum
Duty Cycle - Air Tools
Industrial Duty
Body Style - Air Tools
Pistol
Duty
Industrial
Torque Range
25 to 165 ft.-lb.
Required Pressure
90 psi
Max. Bolt Capacity
1/2 in
Average CFM @ 15 Second Run Time
4.20
Item - Air Impact Wrenches
Air Impact Wrench
Blows per Minute - Air Tools
1600
Anvil Type - Air Impacts
2" Extended
Standards
EN ISO 11148-6:2013, ISO-28927-2
Exhaust Location
Bottom
Impact Rated
Yes
Air Pressure
90 psi
Drive Type
Extended
Impact Sound Level
104 dB
Impacts per Minute
1,600
Air Consumption
16 cfm
Power Source
Air-Powered
Number of Speed Settings
4
Clutch Style
Jumbo Hammer
Vibration Level
10.3 m/sq sec
Max. Air Pressure
90 psi
Tool Style
Compact
Fastening Torque
165 ft-lb
Min. Air Pressure
90 psi
Breakaway Torque
220 ft-lb
Power to Weight Ratio
88 ft-lb/lb
Duty Rating
Industrial Duty
Built-In Light
No
Air Pressure - Minimum
90 psi
Air Pressure - Maximum
90 psi
Drive Shape
Square
Bolt Capacity - Maximum
1 in
Tool Life
Long Lasting
Frequency of Use
Maintenance to Light Production
Air Inlet Type
NPT
Power Source - TS Only
Air-Powered

Description

Impact Wrench, Power Source Air Powered, Air Consumption 16 cfm, Air Inlet 1/4 in NPT, Air Pressure 90 psi, Max. Air Pressure 90 psi, Min. Air Pressure 90 psi, Min. Hose Size 3/8 in, Exhaust Location Bottom, Duty Rating Industrial Duty, Breakaway Torque 220 ft-lb, Fastening Torque 165 ft-lb, Free Speed 9,000 RPM, Impact Rated Yes, Impact Sound Level 104 dB, Impacts per Minute 1,600, Number of Speed Settings 4, Power to Weight Ratio 88 ft-lb/lb, Max. Bolt Capacity 1/2 in, Drive Size 1/2 in Square
