Surge Protection Device, 1 Phase, 120V, 2 Poles, 2 Wires
Mfr # DS72US-120S
Zoro # G802664346
product price: $183.99
/ea
Free Shipping & Returns
Key Features
Mounting Style
Din Rail
Phase
1
Voltage
120V
Number of Poles
2
Number of Wires
2 Wires
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
DS72US-120S
Zoro #
G802664346
UPC #
-
Country of Origin
China
Dimensions
Length
90 mm
Depth
36 mm
Width
67 mm
Details
Item
Surge Protection Device
Mounting Style
Din Rail
Phase
1
Voltage
120V
Number of Poles
2
Voltage Protection Rating
800V/1200V/700V
Number of Wires
2 Wires
Modes of Protection
L-L, L-G, L-N, N-G
Max. Surge Current per Mode
75kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
200kA
Modular
Yes
Max. Continuing Operating Voltage
210V/360V/150V
IP Rating
IP20
Enclosure Material
Thermoplastic
Standards
UL 1449 Type 1
