Dayton

Belt Drive Mtr, SplitPh, ODP, 1/3HP, 1725rpm

product price: $227.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Manufacturers Warranty Length 1 yr
  • Motor Mounting Position All Angle
  • Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
  • No. of Speeds 1
  • HP 1/3
See all product information

Product Information

Dimensions

Manufacturers Warranty Length 1 yr
Shaft Dia. 5/8 in
Shaft Length 2 7/16 in

Details

Motor Mounting Position All Angle
Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
No. of Speeds 1
HP 1/3
Motor Bearings Ball
Frame Material Rolled steel
Motor Sub Application Belt Drive Fan/Blower
Motor Enclosure Design Open Dripproof
Nameplate RPM 1,725
Frame 56CZ
Item Belt Drive Motor
Voltage 115V AC
Motor Service Factor 1.35
Max. Ambient Temp. 104 Degrees F
Ins. Class B
Motor Design Split-Phase
RPM Range 1,701-1,800
Full Load Amps 5.8 A
Duty Continuous
Phase Single
Motor Shaft Rotation CW/CCW
Hz 60 Hz
Motor Shaft Design Keyed
Standards CE, CSA Certified, UL Recognized
Motor Frame Material Rolled Steel
Motor Thermal Protection None
Motor Application HVAC/R
Motor Mounting Type Face
Duty Cycle Continuous

Description

Belt Drive Motor, Single Phase, Motor Design Split-Phase, 1/3 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, 5.8 A Full Load Amps, 56CZ Frame, 60 Hz Hz, Motor Service Factor 1.35, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Face, Motor Mounting Position All Angle, Motor Frame Material Rolled Steel, Shaft Dia. 5/8 in, Shaft Length 2 7/16 in
