- MFR #
- 5UXG4
- Zoro #
- G2509227
- UPC #
- 190735353134
- Country of Origin
- India
- Item
- Booster Pump
- Booster Pump Type
- Multi-Stage Booster Pump
- HP - Pumps
- 3 hp
- Voltage - Pumps
- 230/460
- Phase - Pumps
- 3
- Number of Stages - Pumps
- 6
- Max. Pressure - Pumps
- 121 psi
- Housing Material - Pumps
- Cast Iron
- Motor Enclosure - Pumps
- Totally Enclosed Fan-Cooled
- GPM @ 40 PSI
- 45
- Frame
- 56J
- Pump Mounting Position
- Horizontal or Vertical with Inlet Down
- Wetted Materials
- Buna N, Carbon/Ceramic, Cast Iron, Stainless Steel
- Duty
- Continuous
- GPM @ 60 PSI
- 38
- Hz
- 60
- Stages
- 6
- GPM @ 20 PSI
- 51
- Best Efficiency GPM @ PSI
- 30 @ 78
- Inlet
- 1-1/4" FNPT
- Suction Lift
- 5 ft with a Foot Valve
- GPM @ 100 PSI
- 17
- Phase
- Three
- Amps
- 7.2/3.6 A
- Housing Material
- Cast iron
- Impeller Type
- Closed
- GPM @ 80 PSI
- 29
- Agency Compliance
- c UL us
- Motor Enclosure
- Totally Enclosed Fan Cooled (TEFC)
- Includes
- Manual
- Impeller Material
- Cast Iron
- Bearing Type
- Ball
- Max. Case Pressure
- 150 psi
- Outlet
- 1" FNPT
- Motor Ambient Temp. Rating
- 40 Degrees C
- Voltage
- 208-230/460
- Motor Type
- 3-Phase
- Max. Liquid Temp.
- 194 Degrees F
- Max. Pressure
- 121 psi
- Motor RPM
- 3,450 RPM
- Seal Material
- Buna-N/Carbon/Ceramic/Stainless Steel
- HP
- 3
- GPM @ 10 PSI
- 54
- Standards
- cULus Listed
- Motor Ambient Temperature (Maximum)
- 104 Degrees F
- Duty Cycle
- Continuous
- Priming
- Manual
- Discharge Type
- NPT
- Flow Rate @ 60 psi
- 38 gpm
- Wetted Material
- Buna-N, Carbon, Cast Iron, Ceramic, Stainless Steel
- Mounting Orientation
- Horizontal
- Flow Rate @ 20 psi
- 51 gpm
- For Use With Potable Systems
- No
- Number of Stages
- 6
- Case Pressure (Maximum)
- 150 psi
- Best Efficiency Pressure
- 78 psi
- Maximum Media Temperature
- 194 Degrees F
- Flow Rate @ 10 psi
- 54 gpm
- Shut Off Pressure (Maximum)
- 121 psi
- Motor Ambient Temperature (Minimum)
- 40 Degrees F
- Flow Rate @ 50 psi
- 41.5 gpm
- Maximum RPM
- 3,450 RPM
- Impeller Design
- Closed
- Flow Rate @ 40 psi
- 45 gpm
- Horsepower
- 3 hp
- Flow Rate @ 70 psi
- 34 gpm
- Suction Lift (Maximum)
- 5 ft
- Flow Rate @ 80 psi
- 29 gpm
- Nameplate Voltage
- 230/460V AC
- Flow Rate @ 30 psi
- 48 gpm
- Compatible with Media Type
- Non-Flammable Liquids, Water
- Motor Frame Designation
- 56J NEMA
- Flow Rate @ 90 psi
- 23 gpm
- Pumping Application
- Dairy Walls and Floors, Lawn Sprinkling and Insecticide Spraying, Rinsing/Spray Cooling Equipment, Washing Buildings
- Intake Type
- NPT
- Frequency
- 60 Hz
- Flow Rate @ 100 psi
- 17 gpm
- Pump Housing Material
- Cast Iron
- Pump Casing Material
- Cast Iron
- Motor Enclosure Design
- Totally Enclosed Fan Cooled
- Case Pressure - Maximum
- 150 psi
- Power Source
- Corded Electric
- Installation
- Floor Standing
- Full Load Current
- 7.2/3.6 A
- Motor Ambient Temperature - Minimum
- 40 Degrees F
- Revolutions Per Minute - Maximum
- 3,450 RPM
- Discharge Standard
- NPT
- Motor Design
- Three-Phase
- Motor Ambient Temperature - Maximum
- 104 Degrees F
- Best Efficiency Flow
- 36 gpm
- Media Temperature - Maximum
- 194 Degrees F
- Media Temperature - Minimum
- 0 Degrees F
- Suction Lift - Maximum
- 5 ft
- Shut Off Pressure - Maximum
- 121 psi
- Inlet Gender
- Female
- Inlet Standard
- NPT
- Feet of Head - Maximum
- 279 ft
- Flow Rate - Maximum
- 54 gpm
- Power Source - TS Only
- Corded Electric
- Power Source - old
- Corded Electric
