Turbine Pump, 1 HP, 1 Ph, 14.4/7.2 Amp

  • Mfr # 4JPE2

  • Zoro # G2480396

product price:  $1,368.99
/ea
Free Shipping & Returns

Key Features

HP
1 hp
Voltage
115/230
Wetted Materials
Bronze, Buna-N, Carbon, Ceramic and 316 Stainless Steel
Seal Material
316 Stainless Steel (Spring), Buna-N/Carbon/Ceramic (Face)
Max. Pressure
120 psi
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
4JPE2
Zoro #
G2480396
UPC #
190735326978
Country of Origin
India

Dimensions

Height
8 1/8 in
Width
6 3/4 in
Overall Width
6.75 in
Overall Height
8.13 in
Compatible Intake Pipe Size
1 1/4 in
Compatible Discharge Pipe Size
1 in
Motor Frame Size
56J
Inlet Diameter
1 1/4 in
Manufacturer Warranty Length
1 yr
Discharge Diameter
1 in
Solid Diameter (Maximum)
0.25 micron

Details

HP
1 hp
Voltage
115/230
Wetted Materials
Bronze, Buna-N, Carbon, Ceramic and 316 Stainless Steel
Seal Material
316 Stainless Steel (Spring), Buna-N/Carbon/Ceramic (Face)
Max. Pressure
120 psi
Impeller Material
Bronze
Motor Enclosure
Open Drip Proof
Inlet
1-1/4 in FNPT
GPM @ 30 PSI
10.6
Outlet
1 in
Max. Case Pressure
200 psi
GPM @ 60 PSI
8.9
Inlet (In.)
1
GPM @ 40 PSI
10
GPM @ 75 PSI
8.3
GPM @ 80 PSI
8
Hz
60
GPM @ 90 PSI
7.5
Inlet Pressure
132 psi
Duty
Continuous
Bearing Type
Ball
Max. Specific Gravity
1
GPM @ 20 PSI
11.1
GPM @ 50 PSI
8.6
Item
Turbine Pump
Housing Material
Bronze
Motor Type
Capacitor-Start/Run
GPM @ 100 PSI
3
Impeller Type
Open
GPM @ 10 PSI
11.2
Agency Compliance
Motor is UL Recognized
Frame
56J
Phase
Single
Motor RPM
3,450 RPM
Best Efficiency GPM @ Head
9.4 @ 50 ft
Amps
14.4/7.2
Features
Designed to Handle Liquids with Entrained Air
Standards
UL Recognized Motor
Best Efficiency Head
50 ft
Flow Rate @ 90 psi
3.7 gpm
Flow Rate @ 10 psi
11.2 gpm
Nameplate Voltage
115/230V AC
Wetted Material
316 Stainless Steel, Bronze, Buna-N, Carbon, Ceramic
Flow Rate @ 80 psi
4.3 gpm
Minimum Flow Rate
3 gpm
Minimum Media Temperature
-20 Degrees F
Frequency
60 Hz
Pump Housing Material
Bronze
Impeller Design
Peripheral Vaned
Case Pressure (Maximum)
200 psi
Flow Rate @ 70 psi
5.8 gpm
Flow Rate @ 20 psi
11.1 gpm
Discharge Type
NPT
Flow Rate @ 60 psi
8.9 gpm
Specific Gravity (Maximum)
1
Flow Rate @ 100 psi
3 gpm
Intake Type
NPT
Shut Off Pressure (Maximum)
120 psi
Seal Type
Mechanical Seal
Duty Cycle
Continuous
NPSHr
304.92 ft
Maximum Flow Rate
11.2 gpm
Horsepower
1 hp
Operation
Manual
Priming
Self-Priming
Motor Frame Designation
56J
Flow Rate @ 40 psi
10 gpm
Flow Rate @ 50 psi
8.6 gpm
Maximum RPM
3,450 RPM
Flow Rate @ 30 psi
10.6 gpm
Flow Rate @ 15 psi
11 gpm
Media Temperature - Maximum
230 Degrees F
Pumping Application
Liquid Transfer
Motor Design
Capacitor-Start/Run
Best Efficiency Flow
4.3 gpm
Pump Design
Regenerative Turbine
Feet of Head (Maximum)
100 ft
Power Source
Electric Motor
Shut Off Pressure - Maximum
120 psi
Shaft Seal Type
Mechanical
Case Pressure - Maximum
200 psi
Flow Rate (Minimum)
3 gpm
Shaft Seal Material
316 Stainless Steel/Buna-N/Carbon/Ceramic
Media Temperature - Minimum
-20 Degrees F
Chemical Compatibility
Non-Flammable Liquids, Water
Mounting Orientation
Horizontal
Ambient Temperature - Maximum
104 Degrees F
Number of Stages
1
Thermal Overload Protection
Yes
Full Load Current
14.4/7.2
Flow Rate (Maximum)
11.2 gpm
Electrical Connection Type
Hardwired
Power Source - TS Only
Electric Motor

Description

Turbine Pump, Phase Single, Pump Housing Material Bronze, Motor Enclosure Open Drip Proof, Horsepower 1 hp, Nameplate Voltage 115/230V AC, Shut Off Pressure (Maximum) 120 psi, Maximum Flow Rate 11.2 gpm, Flow Rate @ 10 psi 11.2 gpm, Flow Rate @ 20 psi 11.1 gpm, Flow Rate @ 30 psi 10.6 gpm, Compatible Intake Pipe Size 1 1/4 in, Compatible Discharge Pipe Size 1 in, Discharge Type NPT, Motor Type Capacitor-Start/Run, Best Efficiency Head 50 ft, Case Pressure (Maximum) 200 psi
