  5. Digital Industrial Pressure Gauge, 0 to 200 psi psi, 3 in Dial, 1/4 in NPT, Bottom Location
No Product Image Available

Digital Industrial Pressure Gauge, 0 to 200 psi psi, 3 in Dial, 1/4 in NPT, Bottom Location

  • Mfr # DPGW-09

  • Zoro # G003481537

product price:  $193.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.00%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
3 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
DPGW-09
Zoro #
G003481537
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
3 in
Case Depth
1.52 in
Manufacturer Warranty Length
1 yr
Digit Height
0.425 in
Case Diameter
2.62 in
Connection Size
1/4 in
Nominal Dial Size
3 in
Battery Size
9V

Details

Item
Digital Industrial Pressure Gauge
Accuracy
+/-1.00%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
OEM Applications, Process Industries
Gauge Case Material
ABS
Series
DPGW
Primary Pressure Range
0 to 200 psi
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Case Material
ABS Thermoplastic
Features
Automatic Shutoff, Zero Adjustment
Includes Mounting Hardware
No
Standards
CE Certified, RoHS, Russian GOST Certification
Sensor Material
Silicone
Display Resolution
0.1 psi
Resolution
Dependent on Range
Includes Batteries
Batteries Included
Includes Calibration Certificate
No
Number of Digits
4
Adjustable Set Points
No
Number of Display Digits
4
Auto-Shutoff
Yes
Display Screen Type
LCD
Low Battery Indicator
Yes
Languages
English
Backlit Screen
No
Case Shape
Round
Socket Material
Stainless Steel
Display Range
0 to 13.79 bar, 0 to 1379 kpa, 0 to 14.06 kg/cm², 0 to 200 psi, 0 to 3200 oz/in², 0 to 461.3 ft wc., 0 to407.2 in Hg
Powered By
9V Battery
Pressure Range Type
Pressure
Primary Display Units
psi
Connection Type
MNPT
Includes
Alkaline Batteries
Weatherproof
No
Case Color
Black
Non-Sparking
No
Gauge Application
For Liquids & Gases
Compatible Process Media
Liquids and Compatible Gases
Primary Display Range
0 to 200
Temperature Error
0.05% Degrees F
Pressure Gauge Type
Industrial Pressure Gauge
Calibration Certificate
No
Display
LCD
Process Temperature Range
30 Degrees to 120 Degrees F
Display Units
bar, in Hg, kg/sq cm, kPa, oz/sq in, psi
Peak Hold
No
Power Source
Battery
Memory Storage
No
Process Connection Gender
Male
Includes Rubber Boot
No
Automatic Shut-Off Time
20 min
Display Type
LCD
Operating Temperature Range
30 Degrees to 120 Degrees F
Process Media Temperature - Minimum
30 Degrees F
Pressure Measuring Units
bar, in Hg, kg/sq cm, kPa, oz/sq in, psi
Pressure Measurement - Maximum
200 psi
Includes Low Battery Indicator
Low Battery Indicator
Pressure Measurement - Minimum
0 psi
Process Media Temperature - Maximum
120 Degrees F

Description

Digital Industrial Pressure Gauge, Accuracy +/-1.00 Percent, Gauge Case Material ABS, Nominal Dial Size 3 in, IP/NEMA Rating Not Rated, Hazardous Location Rating Not Rated, Compatible Process Media Liquids and Compatible Gases, Sensor Material Silicone, Socket Material Stainless Steel, Process Connection Type NPT, Display Units bar, in Hg, kg/sq cm, kPa, oz/sq in, psi, Process Connection Gender Male, Battery Type 9V Battery, Process Connection Location Bottom, Process Connection Size 1/4 in
