Flint & Walling

Deep Well Submersible Pump Motor, 1/2 HP

original price: $683.72
29% off
new price: $478.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Phase Single
  • Dia. 3 3/4 in
  • HP 1/2
  • Voltage 115V AC
  • Number of Wires 3
See all product information

Product Information

Dimensions

Dia. 3 3/4 in
Lead Length 48 in
Height 10 1/8 in
Length Less Shaft 10 1/8 in
Overall Length 11 5/8 in
Body Dia. 4 in

Details

Item Deep Well Submersible Pump Motor
Phase Single
HP 1/2
Voltage 115V AC
Number of Wires 3
RPM Range 3,001-3,600
Motor Service Factor 1.6
Motor Bearings Sleeve
Nameplate RPM 3,450
Motor Application Pump
Hz 60 Hz
Standards CSA (C22.2 No. 100-14), NSF/ANSI 61
Motor Enclosure Design Totally Enclosed Nonventilated
Overload Relay Required No
Shell Material Stainless Steel
Thrust Rating 700 lb
Motor Sub Application Deep Well Submersible Pump
Stator Type Hermetically Sealed
Starter Required No
Shaft Material Stainless Steel
Full Load Amps 10.0
Motor Thermal Protection Auto
Motor Design Split-Phase
Max. Ambient Temp. 86 Degrees F
Motor Shaft Rotation CWSE
Max. SF Amps 12.0
Diaphragm Type Pressure Equalizing
Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Usable @ 200V No
Motor Shaft Design Spline
Motor Mounting Position Vertical Shaft Up
No. of Speeds 1
Usable @ 208V No

Description

Deep Well Submersible Pump Motor, Body Dia. 4 in, Diaphragm Type Pressure Equalizing, Hz 60 Hz, Full Load Amps 10.0, Height 10 1/8 in, HP 1/2, Lead Length 48 in, Length Less Shaft 10 1/8 in, Max. Ambient Temp. 86 Degrees F, Max. SF Amps 12.0, Motor Application Pump, Motor Bearings Sleeve, Motor Design Split-Phase, Motor Enclosure Design Totally Enclosed Nonventilated
