Shop FLINT & WALLING

Deep Well Submersible Pump Motor, 1/2 HP

  • Mfr # 137414

  • Zoro # G2553813

product price:  $795.60
/ea
Free Shipping & Returns

Key Features

Phase
Single
Dia.
3 3/4 in
HP
1/2
Voltage
230V AC
Number of Wires
2
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
137414
Zoro #
G2553813
UPC #
054757035907
Country of Origin
United States

Dimensions

Dia.
3 3/4 in
Height
10 1/8 in
Lead Length
48 in
Body Dia.
4 in
Length Less Shaft
10 1/8 in
Overall Length
11 5/8 in
Shaft Diameter
5/8 in
Body Diameter
4 in

Details

Item
Deep Well Submersible Pump Motor
Phase
Single
HP
1/2
Voltage
230V AC
Number of Wires
2
RPM Range
3,001-3,600
Motor Service Factor
1.6
Motor Bearings
Sleeve
Nameplate RPM
3,450
Motor Shaft Rotation
CWSE
Max. Ambient Temp.
86 Degrees F
Thrust Rating
700 lb
Overload Relay Required
No
Motor Design
Split-Phase
Standards
CSA (C22.2 No. 100-14), NSF/ANSI 61
Diaphragm Type
Pressure Equalizing
Motor Application
Pump
Stator Type
Hermetically Sealed
Motor Thermal Protection
Auto
Starter Required
No
Max. SF Amps
6.0 A
Shaft Material
Stainless Steel
Shell Material
Stainless Steel
Motor Sub Application
Deep Well Submersible Pump
Hz
60 Hz
Full Load Amps
5.0 A
Motor Enclosure Design
Totally Enclosed Nonventilated
Usable @ 200V
Not Usable at 200V
Motor Mounting Position
Vertical Shaft Up
Motor Shaft Design
Spline
Usable @ 208V
Not Usable at 208V
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
No. of Speeds
1
Series
4F
Frequency
60 Hz
Bearing Type
Sleeve
Application
Pump
Mounting Position
Vertical Shaft Up
Number of Speeds
1
Shaft Design
Splined
Service Factor Current
6.0 A
Sub Application
Deep Well Submersible Pump
Includes Diaphragm
Diaphragm Included
Product Type
Pump Motor
Nameplate Service Factor @ 60 Hz
1.6
Requires Overload Relay
No
Motor Enclosure Type
Totally Enclosed Non-Ventilated
Includes Low Temperature Monitor
Low Temperature Monitor Not Included
Full Load Current @ 60 Hz
5 A

Description

Deep Well Submersible Pump Motor, Body Dia. 4 in, Diaphragm Type Pressure Equalizing, Hz 60 Hz, Full Load Amps 5.0, Height 10 1/8 in, HP 1/2, Lead Length 48 in, Length Less Shaft 10 1/8 in, Max. Ambient Temp. 86 Degrees F, Max. SF Amps 6.0, Motor Application Pump, Motor Bearings Sleeve, Motor Design Split-Phase, Motor Enclosure Design Totally Enclosed Nonventilated
