Carbide Turning Insert, Parallelogram, ZCMX080304, for Steel
Mfr # 268425 HBZ025
Zoro # G914822528
product price:Â
$
19.39
/ea
Sold in multiples of 10 for $193.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
ISO Number
ZCMX 080304
Suitable Tool Diameter
16 mm
Insert Material
Carbide
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 268425 HBZ025
- Zoro #
- G914822528
- UPC #
- -
- Country of Origin
- Austria
Dimensions
- Suitable Tool Diameter
- 16 mm
- Insert Size
- 80304
- Min. Cutting Depth (ap min)
- 0.25 mm
- Max. Cutting Depth (ap max)
- 2.75 mm
- Corner Radius
- 0.4 mm
- Insert Thickness
- 2 mm
- Cutting Depth
- 0.4 mm
Details
- Item
- Indexable Insert for Turning
- Insert Shape
- Parallelogram
- Insert Style
- ZCMX
- ISO Number
- ZCMX 080304
- Insert Material
- Carbide
- Coating
- PVD
- No. of Edges
- 2
- Grade
- HBZ025
- Cutting Conditions
- Continuous
- Workpiece Material
- Steel
- Inscribed Circle
- 8 mm
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 16 mm Grade: HBZ025 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 90 210 m/min
