Carbide Turning Insert, Parallelogram, ZCMX080304, for Steel
Mfr # 268425 HBZ030
Zoro # G414822547
product price:Â $18.29
/ea
Sold in multiples of 10 for $182.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
8 mm
Insert Size
80304
Grade
HBZ030
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
268425 HBZ030
Zoro #
G414822547
UPC #
-
Country of Origin
Austria
Dimensions
Insert Size
80304
Corner Radius
0.4 mm
Min. Cutting Depth (ap min)
0.25 mm
Suitable Tool Diameter
16 mm
Cutting Depth
0.4 mm
Insert Thickness
2 mm
Max. Cutting Depth (ap max)
2.75 mm
Details
Item
Indexable Insert for Turning
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
8 mm
Grade
HBZ030
Insert Material
Carbide
ISO Number
ZCMX 080304
Coating
CVD
No. of Edges
2
Workpiece Material
Steel
Cutting Conditions
Continuous
Description
Harder substrate for longer tool life with thinner CVD coating. Especially for facing and longitudinal turning applications. suitable for tool dia. Dc: 16 mm Grade: HBZ030 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 70 200 m/min
