Carbide Turning Insert, Parallelogram, ZCMX10T304, for Steel
Mfr # 268433 HBZ030
Zoro # G114821857
product price:Â $18.89
/ea
Sold in multiples of 10 for $188.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Insert Size
10T304
Grade
HBZ030
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
268433 HBZ030
Zoro #
G114821857
UPC #
-
Country of Origin
Austria
Dimensions
Insert Size
10T304
Corner Radius
0.4 mm
Suitable Tool Diameter
20 mm
Max. Cutting Depth (ap max)
2 mm
Cutting Depth
0.4 mm
Min. Cutting Depth (ap min)
0.4 mm
Insert Thickness
2.5 mm
Details
Item
Indexable Insert for Turning
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Grade
HBZ030
Insert Material
Carbide
Insert Application
Finishing
ISO Number
ZCMX 10T304
Cutting Conditions
Continuous
No. of Edges
2
Workpiece Material
Steel
Description
Harder substrate for longer tool life with thinner CVD coating. Especially for facing and longitudinal turning applications. suitable for tool dia. Dc: 20 mm Grade: HBZ030 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 70 200 m/min
