Shop GENTEQ

Direct Drive Blower Motor, 1/2HP, ECM, 460V

  • Mfr # 6405
  • Zoro # G4313876
product price:
$
502.99
/ea
Free Shipping & Returns

Key Features

HP
1/2
Nameplate RPM
1,075
Voltage
460V AC
Frame
48
Shaft Dia.
1/2 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
6405
Zoro #
G4313876
UPC #
815585023821
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Shaft Length
3 15/16 in
Length Less Shaft
6 5/8 in
Bolt Circle Dia.
5 3/8 in
Body Dia.
5 5/8 in
Manufacturers Warranty Length
1 yr
Overall Length
10 1/2 in
Lead Length
42 in
Bolt Circle Diameter
5 3/8 in
Shaft Diameter
1/2 in
Body Diameter
5.6 in
Frame Size
48
Fits Chest Size
Auto Rotation, Dual Voltage by Plug Selection, Multi-Speed (5 Taps @ 24vac), PWM Auto Recognized

Details

HP
1/2
Nameplate RPM
1,075
Voltage
460V AC
Frame
48
Motor Shaft Rotation
CWSE
RPM Range
1,001-1,100
Application
Fan/Blower
Motor Service Factor
1
Motor Thermal Protection
None
Motor Sub Application
Direct Drive Fan/Blower
Motor Shaft Design
Flat
Duty
Continuous
Motor Application
HVAC/R
Max. Ambient Temp.
40 Degrees C
Ins. Class
B
Capacitor Required
No
Motor Enclosure Design
Open Air-Over
Full Load Amps
2.01 A
Motor Mounting Type
Face
No. of Speeds
5
Motor Design
ECM
Item
Direct Drive Blower Motor
Phase
Single
Motor Bearings
Ball
Motor Mounting Position
Vertical Shaft Down
Hz
60 Hz
Voltage Compatibility
200V AC to 230V AC, 440V AC, 200V AC to 230V AC, 460V AC, 208V AC to 220V AC, 440V AC, 208V AC to 230V AC, 460V AC, 220V AC to 230V AC, 460V AC, 220V AC, 460V AC, 230V AC, 460V AC, 796V AC, 230V AC, 460V AC, 440V AC to 460V AC, 460V AC, 796V AC, 460V AC
Weight
14 lb
Usable @ 208V
No
Usable @ 200V
No
Motor Frame Material
Steel
Duty Cycle
Continuous
Number of Shafts
1
Includes
Optional Crimp Connect Terminals, Optional Low Voltage Wiring Harness, Voltage Plugs
Mounting Holes
4
Stud Quantity
4
Series
Evergreen(R) CM
Frame Material
Steel
Wattage
370 W
Mounting Position
Vertical Shaft Down
Ambient Temperature - Maximum
40 Degrees C
Number of Speeds
5
Features
Auto Rotation, Dual Voltage by Plug Selection, Multi-Speed (5 Taps @ 24vac), PWM Auto Recognized
Manufacturers Warranty
1 yr
Shaft Design
Flat
External Control Type
Building Management System Low Voltage Controller, PWM Controller
Full Load Current @ 60 Hz
2.01 A
Rated Horsepower
1/2 hp
Sub Application
General Purpose
Motor Enclosure Type
Open Air Over
Product Type
Fan and Blower Motor
Includes User Interface
User Interface Not Included
Frequency
60 Hz
Control Connector Configuration
9-Pin
Nameplate Service Factor @ 60 Hz
1
Insulation Class
B
ECM Motor Type
Constant Torque
Compatible with External Controller
External Control Compatible
Bearing Type
Ball

Description

Direct Drive Blower Motor, 48
