  6. ForgeMaster Swivel Caster, 8" x 3" Ergo-Glide XT Wheel, 3/4" Sealed Precision Ball Bearings
Hamilton ForgeMaster Swivel Caster, 8" x 3" Ergo-Glide XT Wheel, 3/4" Sealed Precision Ball Bearings S-FM-83EGB - main

ForgeMaster Swivel Caster, 8" x 3" Ergo-Glide XT Wheel, 3/4" Sealed Precision Ball Bearings

  • Mfr # S-FM-83EGB

  • Zoro # G1257958

product price:  $288.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Wheel/Tread Material
Cast Iron/Polyurethane
Wheel Dia.
8
Wheel Width
3
Mounting Height
10.25
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S-FM-83EGB
Zoro #
G1257958
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
8
Wheel Width
3
Mounting Height
10.25
Mounting Plate Size
4 1/2 x 6 1/2
Mounting Bolt Dia.
0.5
Stem Dia.
No Stem
Overall Height
10-1/4in

Details

Item
Swivel Fm 8X3 Ergo-Glide Xt
Caster Sub-Type
Swivel
Wheel/Tread Material
Cast Iron/Polyurethane
Load Rating
2700
Wheel/Tread Color
Blue
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Forged Steel
Core Color
Gray
Non-Marking
No
Number of Wheels
1
Outside Bolt Hole Spacing
3 3/8 x 5 1/4
Inside Bolt Hole Spacing
2 7/16 x 4 15/16
Caster Plate Hole Pattern
A
Caster Stem Type
No Stem/Plate Included
Caster Brake Included
No
Replacement Wheel
W-831-EGB-3/4
Standards
ICWM
Frame Finish
Powder Coat
Thread Guards
No
Series
ForgeMaster™
Wheel/Tread Hardness Rating
Hard
Wheel Core Material
Cast iron
Load Rating Range
Heavy-Duty
Operating Temperature Range
-50 to 200 deg(F)

Description

Swivel Fm 8X3 Ergo-Glide Xt
