Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD125R/NW-25A is a pressure regulator intended for regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at a maximum inlet pressure of 500 mbar (7 psig), and provides an adjustable outlet pressure range from 35 to 100 mbar.

Key features include:

• Integrated pilot lamp for operational status indication
• IP65 rated enclosure for protection against dust and water ingress
• FM and SA approvals; EU certified
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on the right side of the connection box
• Outlet equipped with test point for right-hand pressure switch (30–110 mbar)
• Includes two screw plugs as left-side accessories; no inlet flange
