Gas Pressure Regulator with Solenoid Valve, 35–100 mbar, DN15, 24V DC
Mfr # KS88001411
Zoro # G815398917
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD115R/NW-25B is a pressure regulator intended for use in applications requiring gas pressure regulation within the specified parameters. It includes a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161); compatible with gas, air, and biologically produced methane as per manufacturer specifications. The unit operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet connection of DN 15 (1/2") Rp internal thread. Electrical operation is supported by a mains voltage of 24 V DC via an M20 cable gland.
Key features include:
- Outlet pressure range: 35–100 mbar
- Features rapid actuation mechanism as specified by manufacturer design
- Pilot lamp indicator
- IP65 rated enclosure
- FM and SA approvals; EU certified
- No inlet flange; size 1 configuration
- Valve seat: reduced type
- Right-side accessories: pressure switch (30–110 mbar), test point for outlet pressure
- Left-side accessories: two screw plugs
