Solenoid Gas Safety Valve - 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS240R/LW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. It operates with a maximum pressure of 500 mbar and is configured to be closed when not energized. The unit features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. The valve is certified according to EN 161, EU, FM, and CSA requirements. It is rated with ratings up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available operation types include quick opening/closing or slow opening/quick closing
• Mains voltage compatibility: rated for operation at mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Versions available with optional position indicators, visual indicators, bypass/pilot gas valves fittings, or integrated pressure switches
