Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VCS9125F05NNAGL3B/PMPM/3-PM is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It is manufactured to meet the requirements of EN 161 standards, configured to remain closed when de-energized. This model supports a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment mechanisms. The unit is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches (DG../VC)
• Certified as meeting the requirements for SIL 3 and PL e
