Snap Action Switch - V15W Series, SPDT, Lever Roller, 5A 240V, IP67
Mfr # V15W-DZ200A04-W2
Zoro # G4709056
product price: $10.19
/eaKey Features
Actuator Type - Snap Action Switch
Lever, Simulated Roller
AC Contact Rating - Snap Action Switch
5 A @ 240 V
DC Contact Rating - Snap Action Switch
5 A @ 30 V
Contact Form- Switches
SPDT
Lever Actuator Length - Snap Action Switch
1.28 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
V15W-DZ200A04-W2
Zoro #
G4709056
UPC #
-
Country of Origin
United States
Dimensions
Lever Actuator Length - Snap Action Switch
1.28 in
Height - Snap Action Switch
0.63 in
Width - Snap Action Switch
1.3 in
Depth - Snap Action Switch
0.41 in
Mounting Dimension
22.20 x 10.3mm Centers
Depth
0.41"
Height
0.63"
Mounting Dimension - Snap Action Switch
0.87 in Centers
Length
1.3"
Actuator Length
1.28"
Lever Actuator Length
1.28 in
Mounting Hole Diameter
7/8 in
Overall Height
0.63 in
Body Width
1.3 in
Body Depth
0.41 in
Overall Width
1.3 in
Overall Depth
0.41 in
Body Height
0.62 in
Description
Honeywell MICRO SWITCH V15W Series Miniature Snap Action Switch features a simulated roller lever actuator and is rated for operation within specified voltage and current ranges (up to 10 A). This switch is constructed with materials and features suitable for industrial environments, with an IP67-rated sealed housing that provides ingress protection as defined by the standard. Electrical connectivity is provided via 3/16 in quick connect terminals, and the unit carries certifications from CQC, ENEC, UL, and cUL.
Key features:
- Actuator: Lever type with simulated roller; length 1.28"
- Contact form: SPDT (1NO/1NC)
- AC contact rating: 5 A @ 240 V
- DC contact rating: 5 A @ 30 V
- Body material: PBT polyester thermoplastic
- Operating temperature range: -40°F to 185°F
- Mounting dimension: 0.87 in centers; mounting hole diameter: 7/8 in
- Differential travel maximum: 0.04 in; max pretravel: 0.13 in; overtravel: up to 0.07 in
- Overall dimensions (WxHxD): 1.3 x 0.63 x 0.41 in
- Terminal type: Quick connect
