  11. Straight Blade Plug, 18-60P, 60 A, 120/208V AC, 4 Pole, Screw Terminals, Non-Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 18-60P, 60 A, 120/208V AC, 4 Pole, Screw Terminals, Non-Grounded HBL7303C - main

Straight Blade Plug, 18-60P, 60 A, 120/208V AC, 4 Pole, Screw Terminals, Non-Grounded

  • Mfr # HBL7303C

  • Zoro # G0336217

product price: $122.92
/ea
Free Shipping & Returns

Key Features

NEMA Plug Configuration
18-60P
Current Rating
60 A
Voltage Rating
120/208V AC
Phase
Three
Number of Poles
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL7303C
Zoro #
G0336217
UPC #
783585015385
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
1.31 in
For Minimum Cable Diameter
0.625 in
Cord Size
0.625 in to 1.310 in
Body Length
4.13 in
Maximum Wire Size
4 AWG
Minimum Wire Size
12 AWG
Outside Diameter
2.88 in
Dimensions
4.13 in x 2.88 in x 2.88 in
Width
2.88 in
Length
4.13 in
Wire Size
#12 AWG to #4 AWG
Height
2.88 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
18-60P
Current Rating
60 A
Voltage Rating
120/208V AC
Phase
Three
Number of Poles
4
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Non-Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
HP
7.5
Voltage
120/208VAC
Boot Code
C
Grade - Plugs and Receptacles
Industrial
Corrosion Resistant
Yes
Material
Nylon
Antimicrobial
No
NEMA Plug Configuration - Plugs and Receptacles
18-60P
Grade
Industrial
Special Features
Corrosion resistant
Phase - Plugs and Receptacles
3
Number of Wires
4
Polarized
Yes
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
167 Degrees F
Insulation Material
Nylon
Horsepower Rating
7 1/2 hp
Housing Material
Nylon
Market
Commercial, Industrial
UL 94 Flammability Rating
HB
Body Style
Straight
Dielectric Strength
Withstands 2,000V minimum.
Terminal Screw Material
3/8" Allen Head, Plated Steel
Flammability
UL 94 HB or better.
Blade Holder Material
Nylon
Box Terminals Material
Copper
Weight (Lbs.)
0.85
Contact Blades Material
.075" Brass
Cord Clamp Material
Glass Reinforced Polyester
Retainer Material
Glass Reinforced PET
Operating Temp.
Maximum continuous 75°C, minimum -40°C (w/o impact).
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 HB Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
OEM Brand Name
Hubbell Wiring Device-Kellems
Horsepower - Maximum
7.5
Industry Standard(s)
CSA Certified UL Listed File E1706
Cord Range
0.625"-1.310"

Description

Straight Blade Plug, Connection Orientation Straight, Current Rating 60 A, Grounding Non-Grounded, Horsepower Rating 7 1/2 hp, Housing Color Black, IP Rating IP20, NEMA Plug Configuration 18-60P, Number of Blades 4, Number of Poles 4, Phase Three, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating HB, Voltage Rating 120/208V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 1.31 in, For Minimum Cable Diameter 0.625 in
