  11. Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded HBL5666CA - main

Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL5666CA

  • Zoro # G0748404

product price: $30.15
/ea

Key Features

NEMA Plug Configuration
6-15P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL5666CA
Zoro #
G0748404
UPC #
783585175652
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.655 in
For Minimum Cable Diameter
0.325 in
Cord Size
0.325 in to 0.655 in
Body Length
2.11 in
Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG
Wire Size
#18 AWG to #10 AWG
Width
1.53 in
Dimensions
2.11 in x 1.53 in x 1.22 in
Length
2.11 in
Height
1.22 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
6-15P
Current Rating
15 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black, White
IP Rating
IP20
Standards
CSA C22.2, UL 498
Resistance Properties
Corrosion Resistant
Antimicrobial
No
Grade - Plugs and Receptacles
Industrial
Number of Wires
3
NEMA Plug Configuration - Plugs and Receptacles
6-15P
Phase - Plugs and Receptacles
1
Corrosion Resistant
Yes
Grade
Industrial
Material
Nylon
Special Features
Corrosion resistant
HP
1.5
Voltage
250VAC
Polarized
Yes
Insulation Material
Nylon
Housing Material
Nylon
Horsepower Rating
1 1/2 hp
Market
Commercial, Industrial
Maximum Operating Temperature
167 Degrees F
UL 94 Flammability Rating
HB
Minimum Operating Temperature
-40 Degrees F
Contact Blades Material
.060" (1.5) Brass
Blade Holder Material
Nylon-Natural
Blade Material
Solid Brass
Body Style
Angle
Weight (Lbs.)
0.15
Ground Screw Material
#8-32 Brass, Multiple Drive (Green)
Environment
Dry
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Retainer Material
Polycarbonate-Clear
Flammability
Rated HB or better UL94
Dielectric Strength
Withstands 2000V per UL498
Terminal Screw Material
#8-32 Brass /Ni plated for neutral
Ground Contact Blade Material
.040" (1.0) Copper Alloy
Operating Temp.
-40°C to 60°C; Maximum continuous 75°C; minimum -40°C (w/o impact)
Cord Clamp Material
Nylon-Natural
Body Material
Impact Modified Nylon
Series
Insulgrip
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 HB or better Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Cord Accomodation - .325"-.655"(8.3-16.6) Mechanical - Terminal Accommodation - #18-10 AWG. Standed copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Style
Angled
OEM Brand Name
Hubbell Wiring Device-Kellems
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Wattage
3750 W
Industry Standard(s)
CSA Certified to C22.2 No. 42 File 280 NEMA® WD-6 Compliant UL Listed to UL498 File E1706
Horsepower - Maximum
1.5

Description

Angle Straight Blade Plug, Connection Orientation Angled, Current Rating 15 A, Grounding Grounded, Horsepower Rating 1 1/2 hp, Housing Color Black, White, IP Rating IP20, NEMA Plug Configuration 6-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating HB, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.655 in, For Minimum Cable Diameter 0.325 in
