Shop JOHNSON CONTROLS

Line Voltage Thermostat, 14 to 30V DC, 20 to 30V AC, Output: 0 to 10V DC, 0 to 5V DC

  • Mfr # HE-68P3-0N00WS
  • Zoro # G7245481
product price:
$
432.99
/ea
Free Shipping & Returns

Key Features

Display Type
LED
Switch Type
DIP
Voltage
14 to 30V DC, 20 to 30V AC, Output: 0 to 10V DC, 0 to 5V DC
For Use With
Any BAS/DDC System
Features
Controller Configuration Dip Switch, Manual Override Pushbutton, Power Supply Selection Switch, User-Selectable Humidity Output, Warmer/Cooler Setpoint Dial
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HE-68P3-0N00WS
Zoro #
G7245481
UPC #
-
Country of Origin
Mexico

Dimensions

Overall Length
1-1/4 in
Overall Height
3-1/4 in
Overall Width
3-1/4 in
Fits Chest Size
Controller Configuration Dip Switch, Manual Override Pushbutton, Power Supply Selection Switch, User-Selectable Humidity Output, Warmer/Cooler Setpoint Dial

Details

Display Type
LED
Switch Type
DIP
Voltage
14 to 30V DC, 20 to 30V AC, Output: 0 to 10V DC, 0 to 5V DC
Item
Line Voltage Thermostat
For Use With
Any BAS/DDC System
Features
Controller Configuration Dip Switch, Manual Override Pushbutton, Power Supply Selection Switch, User-Selectable Humidity Output, Warmer/Cooler Setpoint Dial
Agency Compliance
UL
Includes
Screw Terminal Block Terminations that Provide Flexibility for Field Wiring, Power Supply
Standards
Energy Management Equipment, File E107041, CCN PAZX, UL Listed, UL Listed 916
Relative Humidity Range
0 to 100%
Output
0 to 10V DC, 0 to 5V DC
Temperature Accuracy
+/-0.35 Degrees F
Electrical Connection Type
Screw Terminal
Series
HE-6800
Power Required
18 to 25 mA at 20 to 30V AC, 4.5 to 7.5 mA at 14 to 30V DC
RH Sensor
Temperature
Includes Power Supply
Yes
Relative Humidity Accuracy
+/-3% of Full Scale
Minimum Operating Temperature
32 Degrees F
Maximum Operating Temperature
131 Degrees F
Housing Material
Thermoplastic
Sensing Element Type
Platinum

Description

Line Voltage Thermostat, Mounting Location Wall Mount, Output 0 to 10V DC, 0 to 5V DC, Temperature Accuracy +/-0.35 Degrees F, Electrical Connection Type Screw Terminals, Enclosure Material Thermoplastic, Display Type LED, Sensing Element Type Platinum, Overall Width 3 1/4 in, Overall Length 1 1/4 in, Overall Height 3 1/4 in, Maximum Operating Temperature 131 Degrees F
