  5. Industrial Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location
Pic Gauges Industrial Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location PRO-202L-254D - main

Industrial Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location

  • Mfr # PRO-202L-254D

  • Zoro # G5119348

product price:  $18.79
/ea

Key Features

Accuracy
+/-2-1-2%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
PRO-202L-254D
Zoro #
G5119348
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Length
2.09"
Nominal Dial Size
2 1/2 in
Case Diameter
2.65 in
Manufacturer Warranty Length
1 yr
Case Depth
1.21 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Industrial Pressure Gauge
Accuracy
+/-2-1-2%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
General Purpose
Gauge Case Material
Stainless Steel
Series
202L
Lens Material
Polycarbonate
Primary Pressure Range
0 to 60
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
Yes
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Primary Range Smallest Graduation
0.5
Calibration Certificate Included
No
Gauge Application
General Purpose
Smallest Graduation
0.5 psi
Gauge Filled With
Glycerin
Includes
Vent Plug
Case Color
Metallic
Case Material
Stainless Steel
Socket Material
Copper Alloy
Wetted Materials
Copper
Standards
ASME
Connection Type
MNPT
Includes Calibration Certificate
No
Non-Sparking
No
Includes Mounting Hardware
No
Secondary Pressure Range
0 to 4
Ambient Operating Temperature Range
-30 Degrees to 180 Degrees F
Dial Color
White
Cleaned for Oxygen Service
No
Dry Dampening Feature
None
Gauge Case Liquid
Glycerin
Primary Scale Minor Graduations
0.5
Bezel Mounting Type
Fixed
Process Connection Gender
Male
Pressure Gauge Type
Industrial Pressure Gauge
Field Fillable
No
Scale Type
Dual
Secondary Scale Units
bar
Removable Bezel
No
Vibration Resistance
Liquid-Filled
Sensor Material
Copper Alloy
Accuracy Grade
ASME B40.100 Grade A
Includes Vent Plug
Yes
Accuracy Scale
Mid-Scale
Pointer Color
Black
Pressure Range Type
Pressure
Pointer Material
Aluminum
Bezel Material
Stainless Steel
Freeze Resistant Movement
No
Maximum Pressure
60
Operating Temperature Range
30 Degrees to 160 Degrees F
Operating Temperature - Maximum
180 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 bar
Primary Scale Pressure Measurement - Minimum
0 psi
Process Media Temperature - Maximum
160 Degrees F
Compatible with Series
202L
Primary Scale Pressure Measurement - Maximum
60 psi
Case Liquid
Glycerin
Process Media Temperature - Minimum
30 Degrees F
Primary Scale Vacuum Measurement - Minimum
0 psi
Primary Scale Vacuum Measurement - Maximum
60 psi
NEMA Enclosure Rating
No Enclosure
Secondary Scale Pressure Measurement - Maximum
4 bar
Secondary Scale Vacuum Measurement - Minimum
0 bar
Operating Temperature - Minimum
-30 Degrees F
Compatible with Brand
Universal

Description

Industrial Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-2-1-2 Percent, Gauge Case Material Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Center Back, Case Color Metallic, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 60, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color White
