Keystone LED Driver, 0-10V, 4-1/2 in - L, 1PK KTLD-15-UV-PS350-42-VDIM-LP1 - main

LED Driver, 0-10V, 4-1/2 in - L, 1PK

  • Mfr # KTLD-15-UV-PS350-42-VDIM-LP1

  • Zoro # G400905834

product price:  $31.69
/ea

Key Features

Power Output
15 W
Environmental Rating
Dry Location
Length
4 1/2 in
Width
1 5/16 in
Height
15/16 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KTLD-15-UV-PS350-42-VDIM-LP1
Zoro #
G400905834
UPC #
-
Country of Origin
China

Dimensions

Length
4 1/2 in
Width
1 5/16 in
Height
15/16 in

Details

Item
LED Driver
Power Output
15 W
Environmental Rating
Dry Location
For Use With
LED Lighting
Input Voltage
120 to 277V AC
Power Factor
Greater Than 0.9
Input Power
15 W
Output Current
260 mA, 290 mA, 320 mA, 350 mA
Output Voltage
20 to 42V DC
Ambient Temp. Range
-40 Degrees to 140 Degrees F
Number of Bulbs Supported
1
Dimming Type
Full Continuous Dimming
Dimming Range
100% to 10%
Dimming Method
0-10V
Case Form Factor
Compact
Driver Mounting Location
Remote Mount
Driver Class
Class 2
Profile
Standard Profile
Output Technology
Programmable
Ouput Constant
Constant Current
Intended LED Usage
Fixture Array
Standards
ANSI C63.4:2009 Class B, EN61000-3-2 (Harmonic Current Emissions Class C), EN61347-1, EN61347-2-13, UL 8750, Class P, UL1310 Class 2
Dimming
Yes
Max. Case Temp.
194 Degrees F
Number of Fixtures
1
Max. Ambient Temp.
140 Degrees F
Power Output - Minimum
5.2 W
UL Type
Type C
Power Output - Maximum
15 W
Total Harmonic Distortion
20 %
Driver Life Expectancy
85,000 hr
Frequency
50/60 Hz
Power Factor - Minimum
0.9
Min. Ambient Temp.
-40 Degrees F
Input Current - Maximum
0.16 A

Description

LED Driver, Intended LED Usage Fixture Array, Number of Bulbs Supported 1, 120 to 277V AC Input Voltage, 20 to 42V DC Output Voltage, 260 mA, 290 mA, 320 mA, 350 mA Output Current, 15 W Input Power, 15 W Power Output, 4 1/2 in Length, 1 5/16 in Width, 15/16 in Height, Case Form Factor Compact, Standard Profile, Class 2

Restrictions

This item has been restricted from sale in the following states: AK, GU, NM, PR, VI
