Shop LEESON

Oil Burner Motor, 1/2 hp

  • Mfr # 048C34D2028
  • Zoro # G4784829
product price:
$
268.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
HP
1/2
Nameplate RPM
3,450
Frame
48NZ
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
048C34D2028
Zoro #
G4784829
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Length
1 3/4 in
Manufacturers Warranty Length
1 yr
Body Dia.
6 3/4 in
Shaft Dia.
1/2 in
Overall Length
10 13/16 in
Length Less Shaft
9 1/8 in
Lead Length
20 in
Shaft Diameter
1/2 in
Frame Size
48NZ
Body Diameter
6.8 in
Wire Rope Length
10 13/16 in
Length
10 13/16 in

Details

Item
Oil Burner Motor
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
HP
1/2
Nameplate RPM
3,450
Frame
48NZ
Voltage
115V AC, 208V AC to 230V AC
Motor Mounting Type
Face
Motor Shaft Rotation
CW/CCW
Motor Application
HVAC/R
Ambient Temperature
40 Degrees C
Voltage Compatibility
115V AC, 200V AC to 230V AC, 115V AC, 208V AC to 230V AC, 115V AC, 208V AC to 230V AC
Phase
Single
Motor Flange Material
Aluminum
Motor Service Factor
1
Motor Thermal Protection
Manual
Motor Sub Application
Oil Burner
Ins. Class
B
Max. Ambient Temp.
40 Degrees C
RPM Range
3,001-3,600
Full Load Amps
7.4/3.5-3.7 A
Hz
60 Hz
Motor Bearings
Ball
Motor Flange Type
Non-Ventilated
Standards
CE Listed, CSA Certified, UL Recognized
Motor Shaft Design
Flat
Features
NEMA N or M Flange Direct, Two Bolt
No. of Speeds
1
Motor Frame Material
Steel
Capacitor Required
Capacitor Included
Output Watts
370 W
Motor Mounting Position
Horizontal or Vertical Shaft Up
Removable Base
No
Duty Cycle
Continuous
Weight
17 lb
Usable @ 200V
Not Usable at 200V
Usable @ 208V
Usable at 208V
Conduit Box Location
Exterior
Conduit Box Position
F1
Nominal Efficiency
62 %
Flange Type
Non-Ventilated
Manufacturers Warranty
1 yr
Full Load Current @ 60 Hz
7.4/3.5-3.7 A
Number of Speeds
1
Application
Oil Burner
Frequency
60 Hz
Mounting Position
Horizontal
Duty
Continuous
Product Type
Oil Burner Motor
Ambient Temperature - Maximum
40 Degrees C
Frame Material
Steel
Drive Type
Direct Drive
Shaft Design
Flat
Wattage
370 W
Bearing Type
Ball
Sub Application
Oil Burner
Motor Enclosure Type
Open Drip Proof
Insulation Class
B
Nameplate Service Factor @ 60 Hz
1

Description

HVAC Motor, Single Phase, Motor Design Capacitor-Start, 1/2 HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 115/208-230V AC, 7.4/3.5-3.7 A Full Load Amps, 48NZ Frame, Output Watts 370 W, 60 Hz Hz, Usable @ 208V Yes, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Manual, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Face, Motor Frame Material Steel
