Leeson Three-Phase General Purpose Motor, 1 HP, 143T Frame, 230/460V AC Voltage, 1735 rpm Nameplate RPM 143TTFN16040 - main
Shop LEESON

Three-Phase General Purpose Motor, 1 HP, 143T Frame, 230/460V AC Voltage, 1735 rpm Nameplate RPM

  • Mfr # 143TTFN16040

  • Zoro # G5297713

product price:  $729.99
/ea
Free Shipping & Returns

Key Features

HP
1
Nameplate RPM
1735 rpm
Voltage
230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
3.0/1.5 A
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
143TTFN16040
Zoro #
G5297713
UPC #
-
Country of Origin
Mexico

Dimensions

Length Less Shaft
11 7/16 in
Overall Length
14 in
Shaft Dia.
7/8 in
Shaft Length
2 9/16 in
Manufacturers Warranty Length
1 yr

Details

Item
General Purpose Motor
HP
1
Nameplate RPM
1735 rpm
Voltage
230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
3.0/1.5 A
Frame
143T
Motor Bearings
Ball
Motor Service Factor
1.15
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
RPM Range
1701-1800
Phase
Three
No. of Speeds
1
Motor Application
General Purpose
Motor Shaft Rotation
CW/CCW
Voltage Compatibility
200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Hz
60 Hz
Ins. Class
F
Max. Ambient Temp.
40 Degrees C
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Shaft Design
Keyed
Nominal Efficiency
85.5 %
Standards
CE, CSA, UL Recognized
CC Number
CC003A
Motor Thermal Protection
None
Includes
AEGIS SGR Bearing Protection Rings
Inverter Rated
Yes
NEMA Design
B
Duty Cycle
Continuous
Weight
65 lb
Usable @ 200V
No
Usable @ 208V
No

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1735 rpm, Frame 143T, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 3.0/1.5 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, Continuous Duty, 1701-1800
