Legend Valve 1" Lead-Free Press x MNPT 90 Degree Elbow

The Legend Valve 1 inch lead free press x MNPT elbow is designed to provide a dependable 90 degree transition between press connection copper tubing and male NPT threaded piping in residential and commercial plumbing systems. The press end connection eliminates the need for soldering, which reduces installation time, labor costs, and fire risk while maintaining a strong and secure joint. The fitting is compatible with ASTM B88 Types K, L, and M hard drawn copper tubing and can also be used with properly prepared annealed soft copper. An integrated O-ring design allows for easy identification of unpressed connections during pressure testing, improving installation accuracy. With a pressure rating up to 200 PSI, a vacuum rating of 29.2 inches of mercury at 68 degrees Fahrenheit, and an operating temperature range from 0 to 250 degrees Fahrenheit, this elbow delivers reliable performance across a wide range of applications while meeting industry standards for safety and potable water use.

• Ideal for residential and commercial plumbing systems requiring a reliable 90 degree transition from press connection to male NPT threading
• Press end connection eliminates soldering, reducing labor time, material costs, and fire hazards during installation
• Compatible with ASTM B88 Types K, L, and M hard-drawn copper tubing; can be used with annealed soft copper when properly rounded
• Molded O-ring design creates visible leak paths during pressure testing to quickly identify un-pressed connections
• Rated for up to 200 PSI cold working pressure; vacuum-rated to 29.2 in/Hg at 68 degrees F with an operating temperature range of 0-250 degrees F
• Manufactured in accordance with ANSI/ASME B16.51 and ANSI/ASME B1.20.1 standards for performance and thread compatibility
• Certified to NSF/ANSI 61 and NSF/ANSI 372 for safe drinking water use, and compliant with UPC and National Plumbing Code of Canada standards
