LockingPlug, 20A, 2hp, Black;White, Nylon
Mfr # 2321E
Zoro # G522729370
product price:Â
$
24.85
/ea
Key Features
Power and Ground Indicating Light
No
Blade Material
Phosphor Bronze
Standards
ANSI C-73, C22.2 No. 42, CSA File No. E13393, UL 498, W-C-596, WD-6
Phase
Single
Current Rating
20 A
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 2321E
- Zoro #
- G522729370
- UPC #
- -
- Country of Origin
- Mexico
Dimensions
- For Minimum Cable Diameter
- 0.36 in
- For Maximum Cable Diameter
- 0.72 in
- Wire Rope Length
- 3.94 in
- Overall Length
- 3.94 in
- Length
- 3.94 in
Description
Locking Plug, Current Rating 20 A, Housing Color Black, White, Housing Material Nylon, NEMA Plug Configuration L6-20P, Number of Blades 3, Number of Poles 2, Phase Single, Resistance Properties Impact Resistant, Voltage Rating 250V AC, Wire Connection Type Spring Clamp Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.72 in, For Minimum Cable Diameter 0.36 in, Grade General Use, Grounding Grounded, Horsepower Rating 2 hp, IP Rating Not Rated, Midget Locking No, Shrouded No
