Leviton Receptacle Outlet, 15A, Black, 125/250V 5825-E - main

Receptacle Outlet, 15A, Black, 125/250V

  • Mfr # 5825-E

  • Zoro # G722982124

product price:  $6.89
/ea

Key Features

NEMA Receptacle Configuration
5-15R
Voltage Rating
125/250V AC
Features
Smooth Face
Number of Wires
3
Face Plate Height
2.6 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
5825-E
Zoro #
G722982124
UPC #
078477554692
Country of Origin
Mexico

Dimensions

Face Plate Height
2.6 in
Face Plate Width
1.3 in
Minimum Wire Size
14 AWG
Overall Depth
1.1 in
Maximum Wire Size
10 AWG
Mount Hole Center-to-Center Height
1.8 in

Details

NEMA Receptacle Configuration
5-15R
Voltage Rating
125/250V AC
Features
Smooth Face
Number of Wires
3
Market
Commercial
Maximum Operating Temperature
60 Degrees C
Horsepower Rating
1/2 hp
Current Rating
15 A
Wire Connection Type
Screw Terminals
Wiring Method
Back/Side
For Environment
Food and Beverage, Oily/Greasy
UL 94 Flammability Rating
V-2
Number of Outlets
2
Item
Decora Plus Duplex Receptacle Outlet
Standards
CSA, FULS Marking, UL
Contact Material
Brass
Receptacle Type
Duplex
Housing Color
Black
Connection Orientation
Straight
Minimum Operating Temperature
-40 Degrees C
Number of Poles
2
Housing Material
Nylon

Description

Decora Plus Duplex Receptacle Outlet, Connection Orientation Straight, Current Rating 15 A, Housing Color Black, Housing Material Nylon, NEMA Receptacle Configuration 5-15R, Number of Poles 2, Number of Wires 3, Receptacle Type Duplex, Standards CSA, FULS Marking, UL, Voltage Rating 125/250V AC, Wire Connection Type Screw Terminals, Wiring Method Back/Side, Horsepower Rating 1/2 hp, UL 94 Flammability Rating V-2
