Air Drum Pump, 8 gpm, 120 psi, 1:1

  • Mfr # 51009C-S16

  • Zoro # G4861077

product price:  $4,145.99
/ea
Additional $200.00 delivery surcharge applies per item.
See details

Key Features

Type
Mobile
Air Motor Size (In.)
4 1/4 in
Container Size
75 gal
Consumption @ 100 PSI
12 cfm
Working Flow Max. (GPM)
15 gpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
51009C-S16
Zoro #
G4861077
UPC #
-
Country of Origin
United States

Dimensions

Air Motor Size (In.)
4 1/4 in
Container Size
75 gal
Outlet Size
1/2 in NPT
Air Outlet Size
1/2 in
Container Size Included
75 gal
For Container Size
75 gal
Hose Inside Diameter
1/2 in
Adapter Connection Diameter
2 in
Air Inlet Connection Size
1/4 in
Hose Length
180 in
Suction Tube Length
32 in

Details

Item
Air Drum Pump
Type
Mobile
Consumption @ 100 PSI
12 cfm
Working Flow Max. (GPM)
15 gpm
Output
15 gpm
Pump Ratio
1:1
Interval Time Between Cycles (Min.)
0.08 min
Fluid In/Out NPT (F)
1 in/ 1/2 in
Pump for Multiple Outlets
Yes
Fluid Outlet Thread (In.)
1/2 FNPT
Fluid Inlet Thread (In.)
1 FNPT
Outlet Pressure Max. (PSI)
120 psi
Min. Air Inlet Pressure
50 psi
Includes
Filter Regulator, Suction Reversing Valve
Capacity
75 gal
For Use With
Oil
Max. Air Inlet PSI
120 psi
Extract
15 oz per stroke
Air Inlet (In.)
1/4 FNPT
Features
4 Wheel Transfer Cart
For Container Type
Tank
Air Consumption
12 cfm
Power Source
Air
Pump Technology
Piston
Maximum Head Pressure
120 psi
Maximum Outlet Pressure
120 psi
Discharge Tube Outlet OD
3/4 in
Maximum Flow Rate
8 gpm
Maximum Fluid Temperature
150 Degrees F
Container Type Included
Tank
Cart Type Included
Cart
Maximum Viscosity
9,000 cps
Housing Material
Aluminum/Steel
Discharge Connection Type
FNPT
Housing Finish
Powder Coated
Includes Follower Plate
No Follower Plate Included
Suction Tube Material
PVC
Chemical Compatibility
Engine Oil, Gear Lube, Hydraulic Oil
Maximum Head
290 ft
Includes Suction Tube
Yes
Pressure Ratio
1:1
Suction Tube OD
1 in
Duty Cycle
Continuous
Minimum Air Pressure
120 psi
Noise Level
90 dB
Hose Tube Material
Synthetic Rubber
Includes Bung Adapter
Yes
Adapter Connection Standard
FNPT
Hazardous Location Class
Not Rated
Discharge Tube Outlet ID
3/4 in
Includes Nozzle
No
Static Protection
Not Groundable
Wetted Material
Aluminum/Nitrile/Steel/PVC
Standards
CE
Variable Speed
No
For SAE Viscosity Grade - Maximum
140
Meter Type Included
No Meter Included
Includes Discharge Hose
Yes
Includes Spout
No
Air Inlet Connection Type
FNPT
Maximum Air Pressure
120 psi
Container Cover Type Included
No Cover Included
Power Source - TS Only
Air

Description

Air Drum Pump, Max. Air Pressure 120 psi, Suction Tube Material PVC, Discharge Connection Type FNPT, Features 4 Wheel Transfer Cart, Thermal Protection Not Applicable, Air Outlet Size 1/2 in, Air Consumption 12 cfm, Hose Length 180 in, Variable Speed No, Includes Discharge Hose Yes, Noise Level 90 dB, Duty Cycle Continuous, Includes Suction Tube Yes, Includes Bung Adapter Yes, Includes Nozzle No, Includes Spout No
