Air Drum Pump, 4 gpm, 360 psi, 3:1

  • Mfr # M9P20R25ENRM

  • Zoro # G4867219

product price:  $3,529.99
/ea
Additional $400.00 delivery surcharge applies per item.
See details

Key Features

Type
Mobile
Air Motor Size (In.)
3 1/8 in
Container Size
95 gal
Consumption @ 100 PSI
12 cfm
Working Flow Max. (GPM)
4 gpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
M9P20R25ENRM
Zoro #
G4867219
UPC #
-
Country of Origin
Italy

Dimensions

Air Motor Size (In.)
3 1/8 in
Container Size
95 gal
Outlet Size
1/2 in NPT
Air Outlet Size
1/2 in
For Container Size
95 gal
Container Size Included
95 gal
Suction Tube Length
44 in
Hose Inside Diameter
1/2 in
Air Inlet Connection Size
1/4 in
Hose Length
300 in
Adapter Connection Diameter
2 in

Details

Item
Air Drum Pump
Type
Mobile
Consumption @ 100 PSI
12 cfm
Working Flow Max. (GPM)
4 gpm
Output
4 gpm
Pump Ratio
3:1
Interval Time Between Cycles (Min.)
0.08 min
Includes
Manual Tip
Fluid In/Out NPT (F)
1 in/ 1/2 in
Min. Air Inlet Pressure
50 psi
Max. Air Inlet PSI
120 psi
Outlet Pressure Max. (PSI)
360 psi
For Use With
Oil
Fluid Outlet Thread (In.)
1/2 FNPT
Air Inlet (In.)
1/4 FNPT
Capacity
95 gal
Fluid Inlet Thread (In.)
1 FNPT
Pump for Multiple Outlets
Yes
Includes Spout
Yes
Max. Flow Rate
4 gpm
Compatible Chemicals
Oil
Air Consumption
12 cfm
Power Source
Air
Variable Speed
No
Discharge Tube Outlet ID
1/2 in
Maximum Outlet Pressure
360 psi
Container Cover Type Included
No Cover Included
Standards
CE
Maximum Air Pressure
120 psi
Meter Type Included
No Meter Included
Discharge Connection Type
FNPT
Container Type Included
Tank
Nozzle Material
Aluminum
For Container Type
Tank
Wetted Material
Aluminum/Nitrile/Steel
Discharge Tube Outlet OD
1/2 in
Housing Finish
Powder Coated
Hazardous Location Class
Not Rated
Minimum Air Pressure
120 psi
Noise Level
90 dB
Chemical Compatibility
Engine Oil, Gear Lube, Hydraulic Oil
Maximum Viscosity
14,000 cps
Nozzle Operation
Manual
Suction Tube Material
Steel
Maximum Fluid Temperature
150 Degrees F
Pump Technology
Piston
Includes Discharge Hose
Yes
Housing Material
Aluminum/Steel
Suction Tube OD
1 in
Pressure Ratio
3:1
Includes Nozzle
Yes
Includes Bung Adapter
Yes
Includes Follower Plate
No Follower Plate Included
Static Protection
Not Groundable
Maximum Flow Rate
4 gpm
Adapter Connection Standard
FNPT
Air Inlet Connection Type
FNPT
Duty Cycle
Continuous
Cart Type Included
Cart
Includes Suction Tube
Yes
Hose Tube Material
Synthetic Rubber
For SAE Viscosity Grade - Maximum
140
Maximum Head
865 ft
Maximum Head Pressure
360 psi
Power Source - TS Only
Air

Description

Air Drum Pump, Max. Air Pressure 50 psi, Suction Tube Material Steel, Discharge Connection Type FNPT, Thermal Protection Not Applicable, Air Outlet Size 1/2 in, Air Consumption 12 cfm, Hose Length 300 in, Variable Speed No, Includes Discharge Hose Yes, Noise Level 90 dB, Duty Cycle Continuous, Includes Suction Tube Yes, Includes Bung Adapter Yes, Includes Nozzle Yes, Includes Spout Yes
