  11. Surge Protection Device, 1 Phase, 240/480V AC, 2 Poles, 3 Wires
Mersen Surge Protection Device, 1 Phase, 240/480V AC, 2 Poles, 3 Wires STP480S07 - main

Surge Protection Device, 1 Phase, 240/480V AC, 2 Poles, 3 Wires

  • Mfr # STP480S07

  • Zoro # G1606742

product price: $198.77
/ea
Free Shipping & Returns

Key Features

Mounting Style
DIN Rail
Phase
1
Voltage
240/480V AC
Number of Poles
2
Voltage Protection Rating
1200V (L-L), 600V (L-N)
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
STP480S07
Zoro #
G1606742
UPC #
782001477998
Country of Origin
Mexico

Dimensions

Length
4.19 in
Depth
2.81 in
Width
1.38 in

Details

Item
Surge Protection Device
Mounting Style
DIN Rail
Phase
1
Voltage
240/480V AC
Number of Poles
2
Voltage Protection Rating
1200V (L-L), 600V (L-N)
Number of Wires
3 Wires
Modes of Protection
L-L, L-N
Max. Surge Current Per Mode
150kA
Max. Surge Current per Mode
75 kA
Max. Surge Current per Phase
75 kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
200kA
Modular
Yes
Filtering
No
Max. Continuing Operating Voltage
275/550V AC
Enclosure NEMA Rating
NEMA 1
IP Rating
IP20
Enclosure Material
Thermoplastic
Wire Gauge
14 to 4 AWG
Includes
Mechanical Indication
Modular / Nonmodular
Modular
Lightning Impulse Current
75 kA
Standards
ANSI/UL 1449 4th Edition, ANSI/IEEE C62.41.1, C62.41.2, C62.45, RoHS Compliant, Type 1
Amps
75 kA
System Connection
Parallel
Max. Operating Temp.
185 Degrees F
Min. Operating Temp.
-40 Degrees F
Color
Gray
UL SPD Type
Type 1
Basic Material
Nonmetallic
Includes Surge Counter
No
Status Indicator
Mechanical Flag
Replacement Plug L2
SP275U
Connection Terminal Type
Box
Torque Rating
35.4 lb-in
Mcov L-L
550 V
Wiring Range
#4 to #14 AWG
Replacement Plug L1
SP275U
System Configuration
Split Phase
Wire Type
Solid / Stranded CU
Min Storage Temp
-40 °C
Mcov L-N
275 V
Flammability Rating
UL94 V0
Wire Connections
Box
Max Operating Temp
85 °C
Max Storage Temp
85 °C
Response Time
<25 ns
Installation Mounting
DIN Rail
Min Operating Temp
-40 °C
Ac Or Dc
AC
Max Discharge Current Imax 8 20
75kA
Max Discharge Current : Imax (8/20)
75kA
Item Description (ERP)
STP T1 75kA 480/240V SP
Short Description
SPD - Plugable STP 75 Series 240/480V L-N VPR 600V L-N MCOV 275V 75 kA 2-pole
APPROVALS & STANDARDS
ANSI/UL 1449 4th Edition,; ANSI/IEEE C62.41.1, C62.41.2,
Frequency
50/60 Hz
Connection/Terminal Type
Box
MOV Response Time
<25 ns

Description

Surge Protection Device, Nonmetallic, Gray, Amps 75 kA, Depth 2.81 in, Enclosure Material Polyethylene Terephthalate, Enclosure NEMA Rating 1
