10B SEHV M ins Scrw 3+2/16A 830V
Mfr # 936010363
Zoro # G2080903
product price:Â
$
28.99
/ea
Sold in multiples of 3 for $86.97
Key Features
Number of Rows
2
Voltage - Maximum
830V
Material - Contact
Copper Alloy
Wire Size (AWG)
14-20
Insert Series
S-EHV
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 936010363
- Zoro #
- G2080903
- UPC #
- -
- Country of Origin
- China
Dimensions
- Wire Size (AWG)
- 14-20
- Component Size
- 10B «57X27»
- Stripping Length
- 7.00mm
Details
- Number of Rows
- 2
- Voltage - Maximum
- 830V
- Material - Contact
- Copper Alloy
- Insert Series
- S-EHV
- Poles
- 5
- Gender
- Male
- Standard
- CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977
- Current - Maximum per Contact
- 16.0A
- Polarized to Mating Part
- Yes
- Material - Insert
- Polycarbonate
- Series
- 93601
- CSA
- 256883
- Component Type
- Inserts - Screw Terminal Block
- Material - Plating
- Silver
- Product Name
- GWconnect
- Insert Color
- Grey
- Temperature Range - Operating
- -40° to +125°C
- Durability (mating cycles max)
- 500
- UL
- E249674
- Tightening Test Torque
- 0.50 Nm
