Molex 3.96mm KK Hdr Vt RPin VrA 6Ckt 26-20-2061 - main

3.96mm KK Hdr Vt RPin VrA 6Ckt

  • Mfr # 26-20-2061

  • Zoro # G4047650

product price:  $1.19
/ea
Sold in multiples of 85 for $101.15

Key Features

PC Tail Length
4.45mm
Material - Plating Termination
Tin
Duration at Max. Process Temperature (seconds)
5
Pitch - Termination Interface
3.96mm
Orientation
Vertical
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
26-20-2061
Zoro #
G4047650
UPC #
-
Country of Origin
India

Dimensions

PC Tail Length
4.45mm
PCB Thickness - Recommended
1.60mm

Details

Material - Plating Termination
Tin
Duration at Max. Process Temperature (seconds)
5
Pitch - Termination Interface
3.96mm
Orientation
Vertical
Circuits (maximum)
6
Process Temperature max. C
235
Plating min - Mating
5.080µm
Voltage - Maximum
250V
Number of Rows
1
Pitch - Mating Interface
3.96mm
Circuits (Loaded)
6
Current - Maximum per Contact
7.0A
UL
E29179
Max. Cycles at Max. Process Temperature
1
Flammability
94V-2
Material - Resin
Nylon
Stackable
Yes
Material - Metal
Brass
Termination Interface: Style
Through Hole
Plating min - Termination
5.080µm
Material - Plating Mating
Tin
Color - Resin
Natural
Durability (mating cycles max)
25
