Moxa Active Ethernet I/O Server, 6Di/6Relay, Iologik E2214 ioLogik E2214 - main

Active Ethernet I/O Server, 6Di/6Relay, Iologik E2214

  • Mfr # ioLogik E2214

  • Zoro # G4575550

product price: $668.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Isolation
3k VDC or 2k Vrms
Serial Line Protection
15 kV ESD for all signals
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E2214
Zoro #
G4575550
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Isolation
3k VDC or 2k Vrms
Serial Line Protection
15 kV ESD for all signals
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Power Input
24 VDC nominal, 12 to 36 VDC
Initial Insulation Resistance
1000 M ohms (min.) @ 500 VDC
Sensor Type
Wet Contact (NPN or PNP) and Dry Contact
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Stop Bits
1
I/O Mode
DI or Event Counter
Dry Contact
On: short to GND; Off: open
Database
Telcordia (Bellcore)
Ethernet
1 10/100 Mbps RJ45 port
Relay Outputs
6 channels
Altitude
Up to 2000 m
Parity
None
Type
Form A (N.O.) power relay
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Data Bits
8
Pulse Output
0.3 Hz at rated load
Storage temperature
-40 to 85°C (-40 to 185°F)
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Digital Filtering Time Interval
Software Configurable
Power Consumption
170 mA @ 24 VDC
Protection
1.5 kV magnetic isolation
Counter Frequency
900 Hz
Wiring
I/O cable max. 14 AWG
Vibration
IEC 60068-2-6
Contact Current Rating
Inductive Load: 2 A @ 30 VDC, 250 VAC, 110 VAC; Resistive Load: 5 A @ 30 VDC, 250 VAC, 110 VAC
Freefall
IEC 60068-2-32
Digital Inputs
6 channels
Contact Resistance
100 m ohms (max.)
Time
307,239 hrs
Baudrate
1200 to 115200 bps
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Ambient Relative Humidity
5 to 95% (non-condensing)
Safety
UL 508
Common Type
3 points per COM
Shock
IEC 60068-2-27
Mechanical Endurance
1,000,000 operationsElectrical endurance: 100,000 operations @ 5 A resistive load
Protocol
Modbus/RTU
Minimum permitted load
1 A @ 5 VDC

Description

Active Ethernet I/O server, 6DI/6Relay
