  11. Male Disconnect, Blue, 16-14AWG, PK50
Panduit Male Disconnect, Blue, 16-14AWG, PK50 DNF14-250FIM-L - main

Male Disconnect, Blue, 16-14AWG, PK50

  • Mfr # DNF14-250FIM-L

  • Zoro # G0059906

product price: $48.29
/pk 50, $0.97/ea

Key Features

Insulation
Full
For Use With
CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
Insulation Color
Blue
Color Code
Blue
Connection Type
Crimp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
DNF14-250FIM-L
Zoro #
G0059906
UPC #
074983521678
Country of Origin
Mexico

Dimensions

Tab Size
0.032 in x 0.250 in
Overall Length
0.9 in
Barrel Inside Dia.
0.09 in
Width
0.4"
Strip Length
5/16 in
Tab Width
0.25 in
Maximum Wire Size
14 AWG
Tab Thickness
0.032 in
Barrel Inside Diameter
0.09 in
Minimum Wire Size
16 AWG
Overall Length (In.)
0.9
Maximum Wire Insulation Diameter (In.)
0.158
Maximum Metric Conductor Size (mm²)
2.5
Wire Strip Length (mm)
7.1
Minimum Metric Conductor Size (mm²)
1.5
Tab Size (mm)
6.3 x 0.8
Overall Width (In.)
0.42
Overall Width (mm)
10.7
Minimum Wire Size (AWG)
#16
Maximum Wire Insulation Diameter (mm)
4.01
Maximum Copper Conductor Size (AWG)
#14
Overall Length (mm)
22.9
Overall Height (mm)
6.9
Maximum Wire Size (AWG)
#14
Tab Size (In.)
0.250 x 0.032
Overall Height (In.)
0.27
Wire Strip Length (In.)
11933

Details

Item
Male Disconnect
Insulation
Full
For Use With
CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
Insulation Color
Blue
Color Code
Blue
Connection Type
Crimp
Wire Range
16 to 14 AWG
Insulation Type
Nylon
Seam
Butted
Connector Type
Quick Disconnect
Max. Voltage
600 V
Max. Temp.
221 Degrees F
Connection Material
Nickel-Plated Brass
Standards
CSA 22.2 No.153, UL 310
Features
Flame Retardant
Special Features
Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Disconnect can be Inserted and Removed From the Male Tab Without the Use of Tools for Lower Installed Cost, Fully Insulated Design Provides Protection From Electrical Shorts, Internal Wire Stop Assures Proper Length of Insertion Into Terminal Barrel, Providing a Higher Quality Connection, The Internal Wire Stop Assures Proper Wire Insertion Length for a Higher Quality Connection
Insulation Coverage
Full Coverage
Insulation Material
Nylon
Barrel Style
Funnel Entry
Maximum Operating Temperature
221 Degrees F
Minimum Operating Temperature
-60 Degrees F
UL 94 Flammability Rating
HB
Contact Material
Brass
Termination Style
Crimp
RoHS Compliant
Yes
Maximum Voltage
600 V
Terminal Type
Tab
Seam Style
Butted
Contact Finish
Nickel
Disconnect Style
Tab
Finish/Coating
Nickel-Plated
Product Type
Disconnect
Maximum Operating Temperature (°F)
221
Base Material
Brass
Standards Met
UL 310, CSA 22.2 No.153
Maximum Voltage (kV)
0.6
Maximum Operating Temperature (°C)
105
Barrel Type
Funnel
Note
DNF14-250FIM-L replaces DNF14-250FIM-C
Flammability Rating
UL94-HB
Disconnect Type
Male Tab Disconnect
Maximum Voltage (V)
600
Tongue Angle
Straight
Environmentally Friendly
Yes
Product Name
Terminal Connector
Product Material
Brass
Connector Details
1 x Quick Disconnect
Product Color
Blue
Contact Plating
Nickel
Packaging Type
Bottle
Sub Brand
Pan-Term®

Description

Wire Disconnect, Contact Finish Nickel, Contact Material Brass, Disconnect Style Quick Disconnect, Insulation Color Blue, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 221 Degrees F, Minimum Wire Size 16 AWG, Maximum Wire Size 14 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, UL 94 Flammability Rating HB, RoHS Compliant Yes, Seam Style Butted, Standards CSA 22.2 No.153, UL 310
