Shop PANDUIT

Male Disconnect, nylon fully insulated,

  • Mfr # DNF14-250FIM-2K

  • Zoro # G3038028

product price:  $790.99
/pk 2000, $0.40/ea
Free Shipping & Returns

Key Features

For Use With
Crimp press with CA9 (CD9-5B) or CA-800EZ (CD-800-5) applicator
Color Code
Blue
Insulation Type
Fully Insulated
Overall Length
0.9 in
Features
Molded, Flame Retardant
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
DNF14-250FIM-2K
Zoro #
G3038028
UPC #
7498382627
Country of Origin
Mexico

Dimensions

Overall Length
0.9 in
Width
0.4"
Height
0.29 in
Wire Strip Length (mm)
7.1
Overall Width (In.)
0.42
Minimum Metric Conductor Size (mm²)
1.5
Overall Length (In.)
0.9
Tab Size (In.)
0.250 x 0.032
Overall Length (mm)
22.86
Minimum Wire Size (AWG)
#16
Overall Height (In.)
0.295
Maximum Wire Insulation Diameter (mm)
4.01
Maximum Copper Conductor Size (AWG)
#14
Maximum Metric Conductor Size (mm²)
2.5
Wire Strip Length (In.)
11933
Maximum Wire Insulation Diameter (In.)
0.158
Tab Size (mm)
6.3 x 0.8
Maximum Wire Size (AWG)
#14
Overall Height (mm)
7.49
Overall Width (mm)
10.66

Details

For Use With
Crimp press with CA9 (CD9-5B) or CA-800EZ (CD-800-5) applicator
Color Code
Blue
Insulation Type
Fully Insulated
Features
Molded, Flame Retardant
Maximum Operating Temperature (°C)
105
Product Type
Disconnect
Standards Met
UL 310, CSA 22.2 No.153
Finish/Coating
Nickel-Plated
Disconnect Type
Male Tab Disconnect
Tongue Angle
Straight
Maximum Voltage (kV)
0.6
Insulation Material
Nylon
Flammability Rating
UL94-HB
Barrel Type
Funnel
Base Material
Brass
Maximum Voltage (V)
600
Maximum Operating Temperature (°F)
221
Product Color
Blue
Contact Plating
Nickel
Product Name
Terminal Connector
Product Material
Brass
Connector Details
1 x Quick Disconnect
Max Operating Temperature
105 degrees celsius
Product Class
Disconnects

Description

Male Disconnect, nylon fully insulated, 16 - 14 AWG, .250 x .032 tab size
