  11. Mechanical Connector, 600 Kcmil-6 AWG
Panduit Mechanical Connector, 600 Kcmil-6 AWG PCSB600-2-4Y - main

Mechanical Connector, 600 Kcmil-6 AWG

  • Mfr # PCSB600-2-4Y

  • Zoro # G0781720

product price: $67.79
/ea

Key Features

Number of Ports
2
Insulation Material
Clear PVC
Length
2.7"
Width
3"
Height
2.8"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PCSB600-2-4Y
Zoro #
G0781720
UPC #
7498359987
Country of Origin
United States

Dimensions

Length
2.7"
Width
3"
Height
2.8"
Overall Length
2.72 in
Overall Length (In.)
2.72
Maximum Aluminum Conductor Size (kcmil)
600
Overall Height (In.)
2.8
Overall Length (mm)
69.1
Overall Width (In.)
3
Hex Size (mm)
9.53
Minimum Aluminum Conductor Size (AWG)
6
Maximum Copper Conductor Size (kcmil)
600
Minimum Copper Conductor Size (AWG STR)
6
Overall Height (mm)
69.9
Overall Width (mm)
76.2
For Wire Size
6 AWG-600 kcmil

Details

Item
Mechanical Connector,600 Kcmil-6 AWG
Number of Ports
2
Insulation Material
Clear PVC
Application
Aluminum or Copper Code Conductors
Features
Double Sided
Maximum Voltage (V)
600
Standards Met
UL Listed and CSA Certified for use up to 600 V
Base Material
Aluminum
Product Type
Multi-Tap Mechanical Connectors, Double Sided
UL Temperature Rating (°C)
90
Note
PCSB600-2-4Y replaces PCSB600-2-4
Product Line
Pan-Lug
Connector Details
Multi-tap Terminal
Product Color
Clear
Product Name
Pan-Lug Terminal Connector
Product Material
Polyvinyl Chloride (PVC)
Product Class
Wire Termination
Body Material
Aluminum
Head Style
Hex
Color
Clear
Connector Type
Double-Sided
For Conductor Material
Aluminum or Copper
Maximum Operating Temperature
90°C
Standards
UL listed and CSA certified

Description

Mechanical Connector,600 Kcmil-6 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
