One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Yellow
- Mfr # LCAX750-12-3
- Zoro # G404858532
product price:
$
88.35
/ea
Key Features
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
Tongue Width
2.17 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- LCAX750-12-3
- Zoro #
- G404858532
- UPC #
- 7498343608
- Country of Origin
- Mexico
Dimensions
- For Stud Size
- 1 to 2 in
- Barrel Size
- Standard
- Tongue Width
- 2.17 in
- Barrel Length
- 1.66
- Outside Dia.
- 1.5
- Overall Length
- 3.94 in
- Stud Hole Size (mm)
- 12.7
- Wire Strip Length (mm)
- 44.5
- Overall Length (mm)
- 100.1
- Inside Diameter (In.)
- 1.17
- Inside Diameter (mm)
- 29.71
- DLO Copper Flex Conductor Size (kcmil)
- 777.7
- Tongue Width (mm)
- 55.1
- Tongue Thickness (mm)
- 8.1
- Tongue Thickness (In.)
- 0.32
- Outer Diameter (In.)
- 1.5
- Barrel Length (mm)
- 42.2
- Wire Strip Length (In.)
- 37989
- Tongue Width (In.)
- 2.17
- Overall Length (In.)
- 3.94
- Stud Hole Size (In.)
- 1 to 2
- Outer Diameter (mm)
- 38.1
- Barrel Length (In.)
- 1.66
Description
The LCAX750-12-3 One-Hole, Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90°C.
