Shop PANDUIT

Two-Hole Compression Lug, 4 to 2 AWG Max, Standard Barrel, Copper, Gray

  • Mfr # LCD4-14A-L
  • Zoro # G0777520
product price:
$
7.25
/ea

Key Features

For Wire Size
4 to 2 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.55 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
LCD4-14A-L
Zoro #
G0777520
UPC #
7498338304
Country of Origin
Mexico
Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
8
Color Code
Gray
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Features
Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
UL Temperature Rating (°C)
90
Stud Hole Spacing (mm)
16
Base Material
Copper
Tongue Type
Standard
T & B Die Index Number
8
Lug Type
2 Stud Hole Lug
Burndy Die Index Number
8
Finish/Coating
Tin-Plated
Product Type
Copper Compression Connectors - Lugs
Panduit Die Index Number
29
Maximum Voltage (kV)
35
Stud Hole Spacing (In.)
0.63
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories

Dimensions

For Wire Size
4 to 2 AWG
Barrel Size
Standard
Tongue Width
0.55 in
Length
2.26"
Cable Size
4 to 3 AWG STR, 2 AWG SOL
Width
0.55 in
Overall Length
2.26 in
Stud Hole Size (In.)
44930
Inside Diameter (In.)
0.28
Wire Strip Length (In.)
45115
Barrel Length (In.)
0.81
Stud Hole Size (mm)
6.4
Tongue Thickness (mm)
2.3
Tongue Thickness (In.)
0.09
Outer Diameter (In.)
0.38
Wire Strip Length (mm)
22.2
Outer Diameter (mm)
9.65
Overall Length (mm)
57.4
Copper Code Conductor Size (AWG)
4
Barrel Length (mm)
20.6
Tongue Width (In.)
0.55
Tongue Width (mm)
14
Overall Length (In.)
2.26
Inside Diameter (mm)
7.11

Description

Lug Compression Connector,4-3 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
