3/8" Push x 1/4" MNPT Kynar Check Valve

  • Mfr # FB6MCVC4-HBLK-05
  • Zoro # G4397145
product price:
$
22.19
/ea

Key Features

Pipe Size
3/8" x 1/4"
Connection Type
Push x MNPT
Connection
3/8" Tube x 1/4" MNPT
Body Material
PVDF
Sub-Category
Polyvinylidene
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
FB6MCVC4-HBLK-05
Zoro #
G4397145
UPC #
-
Country of Origin
United States

Dimensions

Pipe Size
3/8" x 1/4"
Length
1.41"
Size
3/8" x 1/4"
Pipe or Tube Size - Check Valves
3/8 in x 1/4 in
Pipe or Tube Size
3/8 in x 1/4 in
Nominal Valve Size
3/8 in

Details

Connection Type
Push x MNPT
Connection
3/8" Tube x 1/4" MNPT
Body Material
PVDF
Sub-Category
Polyvinylidene
Item
Check Valve
Min. Temp. - Valves
0 Degrees F
Material of Construction
Kynar
Body Material - Valves
Kynar(R)
Item - Check Valves
Check Valve
Standards
RoHS Compliant
Connection Type - Check Valves
Push x MNPT
Max. Temp.
150 Degrees F
Mechanism and Body Design
Inline Spring
Cracking Pressure
0.5 psi
Flow Design
Single
Mounting Orientation - Check Valves
Horizontal, Vertical
Seal Material - Check Valves
Fluorocarbon
Seat Material - Check Valves
Fluorocarbon
Spring Material - Check Valves
Stainless Steel
Max. Pressure
300 psi
Max. Water Pressure - Valves
150 psi
Full Flow - Valves
Yes
Max. Water Pressure
150 psi
Cracking Pressure - Check Valves
0.500 psi
Max. Temp. - Valves
250 Degrees F
Application - Valves
Corrosives
Max. Steam Pressure - Valves
Not Rated
Seat Material
FKM
Temp. Range
34 Degrees to 150 Degrees F
Spring Material
302 Stainless Steel
Seal Material
FKM
Mounting Orientation
Horizontal, Vertical
Type
Black
Max. Pressure (PSI)
150
NSF Certifications for Food and Drinking Water
NSF 51, NSF 61
Check Mechanism Material
PDVF
Connection Gender - Side 1
Female
Valve Body Style
Inline
Operating Temperature - Maximum
250 Degrees F
Connection Type - Side 2
NPT
Operating Temperature - Minimum
0 Degrees F
Maximum Pressure - Steam
Not Rated
Maximum Pressure - Operating
150 psi
Connection Gender - Side 2
Male
3-A Standard Compliance
Not Rated
Includes Counterweight
No Counterweight
Check Mechanism
Poppet
For Media
Corrosives
Connection Type - Side 1
Push
Silent Check
Standard
Valve Series
Truseal

Description

PARKER FB6MCVC4-HBLK-05 is an inline spring check valve with a single-flow design and poppet check mechanism for systems handling compatible corrosive media within the valve’s material, pressure, and temperature ratings. It features a Kynar body, a 3/8 in push connection on one side, a 1/4 in male NPT connection on the other, and a 0.5 psi cracking pressure. The valve can be mounted horizontally or vertically.

Key Features:

  • Valve type: Inline spring check valve
  • Flow design: Single-flow
  • Application/media: Compatible corrosive media within the valve’s material, pressure, and temperature ratings
  • Body material: Kynar
  • Check mechanism: Poppet
  • Connection type: 3/8 in tube push x 1/4 in MNPT
  • Connection genders: Female side 1, male side 2
  • Maximum operating pressure: 150 psi
  • Temperature range: 0 Degrees F to 250 Degrees F
  • Seal and seat material: Fluorocarbon/FKM
  • Spring material: 302 stainless steel
  • Mounting orientation: Horizontal or vertical
  • Full flow: Yes
  • Standards: NSF 51, NSF 61, RoHS
  • Valve series: Truseal
