Coupler

The PARKER - 21SSTF10MXX is a quick coupler for tool-free connection and disconnection as part of its intended use. Manufactured from brass, it features a hose barb connection type with a 10 mm hose fitting size and a 5 mm body size for the quick connect air coupling. This fitting is intended for use with gas, liquids, and pneumatic media. The product does not include an internal valve component for flow control and has a specified operating temperature range of -40°F to 464°F.

Key Features:

• Constructed from brass material for the main body.
• Hose barb connection designed for use with 10 mm hose fitting size.
• Quick connect air coupling body size of 5 mm.
• Is rated for a maximum flow rate of 550 liters per minute.
• Maximum outside diameter measures 12 mm.
• Is intended for use with gas, liquids, and pneumatic media (per the rated operating parameters).
• Does not include an internal valve component.
• Temperature operating range from -40°F to 464°F.
• Is stated to meet applicable ATEX and RoHS requirements.
• Includes barbed hose tail for secure tubing attachment.
