Pic Gauges Industrial Pressure Gauge, 0 to 6,000 psi, 1 1/2 in Dial, 1/8 in NPT, Center Back Location SEP-102D-158S - main

Industrial Pressure Gauge, 0 to 6,000 psi, 1 1/2 in Dial, 1/8 in NPT, Center Back Location

  • Mfr # SEP-102D-158S

  • Zoro # G7287395

product price:  $4.99
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/8 in
Process Connection Type
NPT
Dial Size (In.)
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
SEP-102D-158S
Zoro #
G7287395
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/8 in
Dial Size (In.)
1 1/2 in
Manufacturer Warranty Length
1 yr
Nominal Dial Size
1 1/2 in
Case Depth
1.06 in
Case Diameter
2.11 in
Nominal Dial Diameter
1 1/2 in

Details

Item
Industrial Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Commercial
Gauge Case Material
Steel
Series
SEP 100
Lens Material
Plastic
Primary Pressure Range
0 to 6,000
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Primary Range Numbered Graduations
1000
Socket Material
Copper Alloy
Gauge Secondary Range Values
0 to 400
Calibration Certificate Included
No
Includes
Plastic Case
Case Color
Black
Graduations
1000 psi
Case Material
Steel
Gauge Application
General-Purpose Case
Connection Type
MNPT
Standards
ASME
Primary Scale Numeric Increments
1,000
Primary Scale Minor Graduations
1,000
Non-Sparking
No
Sensor Material
Copper Alloy
Vibration Resistance
None
Secondary Pressure Range
0 to 414
Field Fillable
No
Removable Bezel
No
Gauge Case Liquid
None
Scale Type
Dual
Includes Calibration Certificate
No
Pointer Color
Black
Includes Mounting Hardware
No
Secondary Scale Units
bar
Pressure Gauge Type
Industrial Pressure Gauge
Accuracy Scale
Mid-Scale
Pressure Range Type
Pressure
Accuracy Grade
ASME B40.100 Grade B
Dial Color
White
Dry Dampening Feature
None
Cleaned for Oxygen Service
No
Process Connection Gender
Male
Includes Vent Plug
No
Pointer Material
Aluminum
Ambient Operating Temperature Range
-40 Degrees to 140 Degrees F
Freeze Resistant Movement
No
Operating Temperature Range
-50 Degrees to 160 Degrees F
Secondary Scale Pressure Measurement - Maximum
414 bar
Secondary Scale Vacuum Measurement - Maximum
400 bar
Primary Scale Pressure Measurement - Minimum
0 psi
NEMA Enclosure Rating
No Enclosure
Primary Scale Vacuum Measurement - Minimum
0 psi
Primary Scale Pressure Measurement - Maximum
6,000 psi
Case Liquid
None
Compatible with Series
SEP 100
Operating Temperature - Minimum
-40 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
Compatible with Brand
Universal
Operating Temperature - Maximum
140 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 bar
Process Media Temperature - Maximum
140 Degrees F
Secondary Scale Vacuum Measurement - Minimum
0 bar
Primary Scale Vacuum Measurement - Maximum
6,000 psi

Description

Industrial Pressure Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Plastic, Process Connection Size 1/8 in, Field Fillable No, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 6,000, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Industrial Pressure Gauge
