  13. IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type
Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type LC1G185BEEA - main

IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type

  • Mfr # LC1G185BEEA

  • Zoro # G510190366

product price: $1,196.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
24V-48V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G185BEEA
Zoro #
G510190366
UPC #
3606481922243
Country of Origin
China

Dimensions

Overall Width
4.25 in
Overall Height
10.04 in
Overall Depth
7.6 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
24V-48V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Series
TeSys Giga
IP Rating
IP20
Mechanical Operating Durability
8,000,000
Minimum Operating Temperature
-13 Degrees F
Maximum Operating Temperature
140 Degrees F
Includes Auxiliary Contacts
Yes
Contactor Style
IEC
Maximum Voltage Rating
1000V AC
Frequency
50/60 Hz
Embedded Surge Suppressor
No
Mounting Style
Plate
Phase
Single
Full Load Current - Inductive
185 A
Full Load Current - Resistive
305 A

Description

Schneider Electric’s IEC Magnetic Contactor is a three-pole, electrically operated switching device designed to control power circuits in accordance with IEC standards. It uses an electromagnetic coil to open or close contacts and is compatible with coils rated between 24-48 V AC/DC, with a 1NC/1NO auxiliary contact arrangement (2 total contacts), and equipped with spring-type terminal connections (specify as per product specifications). Rated for plate mounting as part of the TeSys Giga series, with operation up to 1000 V AC and IP20 protection rating.

Item: IEC Magnetic Contactor

  • Series: TeSys Giga
  • Poles: 3
  • Phase: Single
  • Coil Voltage: 24-48 V AC/DC
  • Auxiliary Contact Form: 1NC/1NO
  • Auxiliary Contacts Included: Yes (2 total)
  • Terminal Connection Type: Equipped with spring-type terminal connections (specify as per product specifications)
  • Mounting Style: Plate
  • Maximum Voltage Rating: 1000 V AC
  • Frequency: 50/60 Hz
  • IP Rating: IP20
  • Mechanical Durability: 8,000,000 cycles
  • Maximum Operating Temperature: 140 Degrees F
  • Minimum Operating Temperature: -13 Degrees F
  • Overall Depth: 7.6 in
  • Overall Height: 10.04 in
  • Overall Width: 4.25 in
  • Embedded Surge Suppressor: No
  • Standards: Complies with applicable standards; compliance does not imply suitability for all applications or environments
