  8. Light block, Harmony XB4, Harmony XB5, for head 22mm universal LED, crew terminal for lugs, 24V
Schneider Electric Light block, Harmony XB4, Harmony XB5, for head 22mm universal LED, crew terminal for lugs, 24V ZBVB19 - main

Light block, Harmony XB4, Harmony XB5, for head 22mm universal LED, crew terminal for lugs, 24V

  • Mfr # ZBVB19

  • Zoro # G300905743

product price:  $38.69
/ea
Sold in multiples of 5 for $193.45

Key Features

Operator Illumination
Illuminated
Terminal Connection
Screw Clamp
Standards
EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-5 || UL 508 || JIS C8201-1
Ambient Air Temperature For Operation
-40-70°C
Ambient Air Temperature For Storage
-40-70°C
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZBVB19
Zoro #
G300905743
UPC #
-
Country of Origin
France

Details

Item
Push Button with Contact Block
Operator Illumination
Illuminated
Terminal Connection
Screw Clamp
Standards
EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-5 || UL 508 || JIS C8201-1
Ambient Air Temperature For Operation
-40-70°C
Ambient Air Temperature For Storage
-40-70°C
Mounting Of Block
front mounting
Current Consumption
18 mA
Connections - Terminals
screw terminals for lug
Supply Voltage Limits
19.2-30 V DC || 21.6-26.4 V AC
Resistance To Fast Transients
2 kV IEC 61000-4-4
Device Short Name
ZBV
Electrical Composition Code
M1 || M2 || M3 || M4 || M5 || M6 || M10 || MF1 || P1 || P2 || PF1
Resistance To Electrostatic Discharge
6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
Protective Treatment
TH
Ip Degree Of Protection
IP20 IEC 60529
Surge Withstand
1 kV IEC 61000-4-5
Light Source
universal LED
Signalling Type
steady
Bulb Base
integral LED
Light Block Supply
direct
Light Source Colour
white
Electromagnetic Emission
class B IEC 55011
[Us] Rated Supply Voltage
24 V, 24 V AC/DC 50/60 Hz
Product Or Component Type
light block
Resistance To Electromagnetic Fields
10 V/m IEC 61000-4-3
Service Life
100000 h at rated voltage and 25°C
Range of Product
Harmony XB4, Harmony XB5

Description

White light block for head 022 integral
