  13. Pilot Light Complete, Red, LED
Shop All Indicator Lights
Schneider Electric

Pilot Light Complete, Red, LED

original price: $63.09
23% off
new price: $47.99
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Voltage 24V AC
  • Color Red
  • Lamp Type LED
  • Shape Round
  • Terminal Connection Screw Clamp
See all product information

Product Information

Dimensions

Size 22 mm
Height 47 mm
Length 54 mm
Width 30 mm
Overall Height 1.85 in
Manufacturer Warranty Length 18 mo
Overall Width 1.18 in
Overall Depth 2.13 in
Panel Cutout Diameter 22 mm

Details

Item Pilot Light
Voltage 24V AC
Color Red
Lamp Type LED
Shape Round
Terminal Connection Screw Clamp
Contact Form (X1-X2)PL
Bezel Chromium Plated Metal
Lens Material Plastic
Lens Type Smooth
Lamp Module Type Full Voltage
Basic Material Metal
Includes Light Module
Body Material Metal
NEMA Rating 13, 4, 4X
IP Rating IP66, IP67, IP69, IP69K
Standards CSA, REACH, RoHS, UL Listed, WEEE
Average Life 100000 hr
Type Steady Signal
Body Finish Chrome Plated
Series XB4
Lamp Color Red
Includes Lens Lens Included
Lens Color Red
Includes Lamp Module Lamp Module Included
Voltage Rating - Maximum 24 V AC/DC
Includes Push-To-Test No Push-To-Test Included
Resistance Properties Dust Resistant, Impact Resistant, Vibration Resistant, Waterproof
NEMA Enclosure Rating 13, 4X

Description

Pilot Light, Voltage 24V AC, Color Red, Lamp Type LED, Shape Round, Terminal Connection Screw Clamp, Lens Material Plastic, 22 mm, Lamp Module Type Full Voltage, Basic Material Metal, Lens Type Smooth, Body Material Metal, NEMA Rating 13, 4, 4X, IP Rating IP66, IP67, IP69, IP69K, Includes Light Module, Standards CSA, REACH, RoHS, UL Listed, WEEE
