  11. Variable Frequency Drive, 15 HP, 400-480V, Altivar 212 AC Drive
Schneider Electric Variable Frequency Drive, 15 HP, 400-480V, Altivar 212 AC Drive ATV212HD11N4 - main

Variable Frequency Drive, 15 HP, 400-480V, Altivar 212 AC Drive

  • Mfr # ATV212HD11N4

  • Zoro # G3374804

product price: $1,565.99
/ea
Free Shipping & Returns

Key Features

Max. HP
15 hp
Input Voltage
380 to 480V AC
Output Voltage
323 to 528V AC
Input Phase AC
Three
Enclosure
Open
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ATV212HD11N4
Zoro #
G3374804
UPC #
785901945048
Country of Origin
Indonesia

Dimensions

Width
7.09 in
Depth
6.69 in
Height
9.13 in
Overall Depth
6 3/4 in
Overall Width
7 1/8 in
Overall Height
9 1/8 in

Details

Item
Variable Speed Drive
Max. HP
15 hp
Input Voltage
380 to 480V AC
Output Voltage
323 to 528V AC
Input Phase AC
Three
Enclosure
Open
Max. Output Amps
22.5 A
Output Phase AC
Three
With Bypass / No Bypass
No Bypass
With Line Contactor / No Line Contactor
No Line Contactor
Dynamic Braking
No
Adjustable Acceleration Time
0.01 to 3,200 sec
Accepts Input Control Signal
Yes
Key Pad Lockout
Yes
Input Frequency
50/60 Hz
Output Frequency Range
0.5 to 200 Hz
Starting Torque
120%
Displays
LED
Protection
Against Exceeding Limit Speed: Drive, Against Input Phase Loss: Drive, Break on the Control Circuit: Drive, Input Phase Breaks: Drive, Line Supply Overvoltage and Undervoltage: Drive, Line Supply Undervoltage: Drive, Motor Phase Break: Motor, Overcurrent Between Output Phases and Earth: Drive, Overheating Protection: Drive, Overvoltage's on the DC Bus: Drive, Short-Circuit Between Motor Phases: Drive, Thermal Power Stage: Drive, Thermal Protection: Motor, With PTC Probes: Motor
Display Type
LED
Adjustable Deceleration Time
0.01 to 3,200 sec
Digital Readout
Hertz, Motor Current, KW, Motor Voltage, Bus Energized
Start/Stop Control
Programmable
Torque @ 1 Hz
110%
Control Method
Keypad or Logic Input
Standards
UL, NOM 117, C-Tick, CSA
For Use With
3-Phase Inverter Duty Motor
Control Type
Keypad, Logic Input
Maximum Output Current
22.5 A
Output Type
Analog, Discrete
Style
Heat Sink
Color
Black
Application
Compressor for Scroll Building - HV AC, Fan Building - HV AC, Pump Building - HV AC
Torque Application
Constant Torque, Variable Torque
Input Voltage Range
380 to 480V AC
Series
ATV212
Ethernet Port Included
No
Input Type
Analog, Discrete
Maximum Output Power
15 hp
Brake Chopper Included
No
Number of Outputs
(1) Analog; (2) Discrete
Enclosure Rating
NEMA 1
Output Voltage Range
380V AC to 480V AC
Number of Inputs
2

Description

Variable Speed Drive, Input Voltage 380 to 480V AC, Input Phase AC Three, Input Frequency 50/60 Hz, Maximum Output Power 15 hp, Maximum Output Current 22.5 A, Output Voltage 323 to 528V AC, Output Phase AC Three, Output Frequency Range 0.5 to 200 Hz, Enclosure Rating NEMA 1
