Shop SCHNEIDER ELECTRIC

Variable Frequency Drive, 3 HP, 230VAC, Altivar

  • Mfr # ATV12HU22M2

  • Zoro # G1018227

product price:  $460.46
/ea
Free Shipping & Returns

Key Features

Max. HP
3 hp
Input Voltage
200-240V AC
Output Voltage
200-240V AC
Input Phase AC
Single
Enclosure
Open
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ATV12HU22M2
Zoro #
G1018227
UPC #
785901897491
Country of Origin
Indonesia

Dimensions

Height
5.12 in
Width
4.13 in
Depth
6.15 in
Overall Height
5 1/2 in
Overall Width
4 1/8 in
Overall Depth
6 1/8 in

Details

Item
Variable Frequency Drive
Max. HP
3 hp
Input Voltage
200-240V AC
Output Voltage
200-240V AC
Input Phase AC
Single
Enclosure
Open
Max. Output Amps
10 A
Output Phase AC
Three
With Bypass / No Bypass
No Bypass
With Line Contactor / No Line Contactor
No Line Contactor
Control Method
Keypad or Remote Keypad or Modbus
Starting Torque
170 %
Control Type
Keypad, Modbus, Remote Keypad
Adjustable Acceleration Time
0 to 999.9 sec
Torque @ 1 Hz
120%
Digital Readout
Yes
Input Frequency
60/50 Hz
Output Frequency Range
0.5 to 400 Hz
Dynamic Braking
No
Standards
UL, C-tick, NOM, GOST, CSA
Accepts Input Control Signal
Yes
Key Pad Lockout
Yes
Displays
LED
For Use With
3-Phase Inverter Duty Motor
Start/Stop Control
Programmable
Protection
Against Input Phase Loss in Three-Phase, Line Supply Overvoltage, Line Supply Undervoltage, Overcurrent Between Output Phases and Earth, Overheating Protection, Short-Circuit Between Motor phases, Thermal Motor Protection via the Drive by Continuous Calculation of I²t
Adjustable Deceleration Time
0 to 999.9 sec
Display Type
LED
Number of Inputs
(2) Analog; (4) Discrete
Input Type
Analog, Digital
Brake Chopper Included
No
Enclosure Rating
NEMA 1
Number of Outputs
(1) Analog; (2) Discrete
Series
Altivar 12
Ethernet Port Included
No
Style
Heat Sink
Maximum Output Power
3 hp
Output Type
Analog
Output Voltage Range
170V AC to 264V AC
Application
Commercial Equipment Mixer, Commercial Equipment Other Application, Textile Ironing
Torque Application
Constant Torque, Variable Torque
Maximum Output Current
10 A
Color
Black
Input Voltage Range
200 to 240V AC
Number of Inputs - Analog
2
Output Frequency - Minimum
400 Hz
Includes Ethernet Port
No
Includes Brake Chopper
No
Number of Outputs - Analog
1
Includes Heat Sink
Yes
Output Horsepower
3 hp
Input Phase
Single
Output Phase
Three
NEMA Rating
NEMA 1
Bypass Design
No Bypass
Line Contactor Design
No Line Contactor
Product Type
Variable Frequency Drive
Output Current - Maximum
10 A
IP Rating
IP20
Keypad Lockout
Yes
Output Frequency - Maximum
0.5 Hz

Description

Variable Frequency Drive, Input Voltage 200-240V AC, Input Phase AC Single, Input Frequency 60/50 Hz, Maximum Output Power 3 hp, Maximum Output Current 10 A, Output Voltage 200-240V AC, Output Phase AC Three, Output Frequency Range 0.5 to 400 Hz, Enclosure Rating NEMA 1
