Schneider Electric Variable Frequency Drive, 7.5HP, 400-480V, Altivar 212 AC Drive ATV212HU55N4 - main

Variable Frequency Drive, 7.5HP, 400-480V, Altivar 212 AC Drive

  • Mfr # ATV212HU55N4

  • Zoro # G1920213

product price:  $1,122.99
/ea
Free Shipping & Returns

Key Features

Max. HP
7.5 hp
Input Voltage
380-480V AC
Output Voltage
323-528V AC
Input Phase AC
Three
Enclosure
Open
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
ATV212HU55N4
Zoro #
G1920213
UPC #
785901917298
Country of Origin
Indonesia

Dimensions

Depth
5.91 in
Width
5.59 in
Height
7.24 in
Overall Height
7 1/4 in
Overall Depth
5 7/8 in
Overall Width
5 5/8 in

Details

Item
Variable Frequency Drive
Max. HP
7.5 hp
Input Voltage
380-480V AC
Output Voltage
323-528V AC
Input Phase AC
Three
Enclosure
Open
Max. Output Amps
12 A
Output Phase AC
Three
With Bypass / No Bypass
No Bypass
With Line Contactor / No Line Contactor
No Line Contactor
Torque @ 1 Hz
110%
Dynamic Braking
No
Adjustable Acceleration Time
0.01 to 3,200 sec
Control Type
Built-In Keypad
Displays
LED
Start/Stop Control
Programmable
Output Frequency Range
0.5 to 200 Hz
Starting Torque
200 %
Adjustable Deceleration Time
0.01 to 3,200 sec
Standards
UL, NOM 117, C-Tick, CSA
Key Pad Lockout
Yes
Protection
Against Exceeding Limit Speed: Drive, Against Input Phase Loss: Drive, Break on the Control Circuit: Drive, Input Phase Breaks: Drive, Line Supply Overvoltage and Undervoltage: Drive, Line Supply Undervoltage: Drive, Motor Phase Break: Motor, Overcurrent Between Output Phases and Earth: drive, Overheating Protection: Drive, Overvoltage's on the DC Bus: Drive, Short-Circuit Between Motor Phases: Drive, Thermal Power Stage: Drive, Thermal Protection: Motor, With PTC Probes: Motor
Display Type
LED
For Use With
3-Phase Inverter Duty Motor
Accepts Input Control Signal
Yes
Control Method
Keypad or Logic Input
Digital Readout
Hertz, Motor Current, KW, Motor Voltage, Bus Energized
Input Frequency
60/50 Hz
Maximum Output Current
12 A
Enclosure Rating
NEMA 1
Number of Outputs
(1) Analog; (2) Discrete
Input Voltage Range
380 to 480V AC
Application
Compressor for scroll Building - HV AC, Fan Building - HV AC, Pump Building - HV AC
Series
ATV212
Color
Black
Maximum Output Power
7 1/2 hp
Number of Inputs
2
Output Type
Analog
Input Type
Analog, Digital
Brake Chopper Included
No
Torque Application
Constant Torque, Variable Torque
Style
Heat Sink
Ethernet Port Included
No
Output Voltage Range
380V AC to 480V AC
Output Phase
Three
Includes Heat Sink
Yes
Output Current - Maximum
12 A
IP Rating
IP20
Input Phase
Three
Bypass Design
No Bypass
Includes Brake Chopper
No
Includes Ethernet Port
No
Output Frequency - Maximum
0.5 Hz
Product Type
Variable Frequency Drive
Output Horsepower
7 1/2 hp
Keypad Lockout
Yes
Line Contactor Design
No Line Contactor
Output Frequency - Minimum
200 Hz
NEMA Rating
NEMA 1
Number of Outputs - Analog
1

Description

Variable Frequency Drive, Input Voltage 380-480V AC, Input Phase AC Three, Input Frequency 60/50 Hz, Maximum Output Power 7 1/2 hp, Maximum Output Current 12 A, Output Voltage 323-528V AC, Output Phase AC Three, Output Frequency Range 0.5 to 200 Hz, Enclosure Rating NEMA 1
