Digital Pressure Gauge, 0.05% FS, -14 to 145 psi Range Industrial Pressure Testing and Calibration
Mfr # EME8REF-C2-0010
Zoro # G822736078
product price:Â
$
982.99
/ea
Free Shipping & Returns
Key Features
Accuracy
0.05 % ± (FS)
Process Connection Type
1/4 BSP with NBR gasket, AF27
Gauge Case Material
Cast Zinc
Primary Scale Units
bar/mbar, kPa/MPa, PSI, kg/cm², mH2O, inH2O
Display
Multifunctional LCD, 4-1/2 digits, with backlight
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- EME8REF-C2-0010
- Zoro #
- G822736078
- UPC #
- 810189500006
- Country of Origin
- Germany
- Accuracy
- 0.05 % ± (FS)
- Process Connection Type
- 1/4 BSP with NBR gasket, AF27
- Gauge Case Material
- Cast Zinc
- Primary Pressure Range
- -14 to 145 PSI
- Primary Scale Units
- bar/mbar, kPa/MPa, PSI, kg/cm², mH2O, inH2O
- Display
- Multifunctional LCD, 4-1/2 digits, with backlight
- Battery Life
- 1500 h
- IP Rating
- IP67
- Battery Type
- 2x 1.5 V AA
- Media Temp Range
- -4 to 176 F
- Logger
- No
- Standards
- Marine DNV
Description
Digital pressure gauges of the C2 series are particularly suitable for both stationary and mobile measurement and display of pressures. The use as a pressure reference allows easy checking, setting and calibration of other pressure measuring devices directly on site - reference pressure gauge for calibration tasks - continuous or temporary checking of different system pressures - air-tightness measurement in building envelopes for the detection and elimination of faults as well as for the reduction of structural damage - checking the degree of contamination of filter systems in ventilation systems or air conditioning systems - recording of pressure drops for the determination of leakage devices in tightness tests - measurement of barometric air pressures for the determination of weather conditions
